Renesas Electronics High Performance CMOS Clock Buffer 8-Pin TSSOP 1.8-3.3V 200MHz Maximum Input Frequency 5PB1104PGGI8

Renesas Electronics 5PB1104PGGI8 is a high performance CMOS Clock Buffer supplied in an 8-pin TSSOP surface mount package. This device operates within a supply voltage range from 1.8V to 3.3V and supports a maximum input frequency of 200MHz, making it suitable for a wide range of clock distribution applications in electronics and electrical systems.

It features very low additive phase jitter of 50fs RMS and very low pin to pin skew, ensuring excellent timing precision. The device incorporates an integrated serial termination for 50 ohm channels to reduce signal reflections, enhancing signal integrity.

The synchronous glitch free output enable function prevents any potential intermediate incorrect output clock cycles when enabling or disabling outputs, improving system reliability.

Its compact size with dimensions of 3.1mm length and 1mm height allows for easy PCB integration within space-constrained designs. Operating temperature range from -40°C to 105°C ensures the device performs reliably in industrial and commercial temperature environments.

This clock buffer is designed primarily for electronics industry applications such as semiconductor and clock distribution circuits utilized in industrial, laboratory, manufacturing, and communication equipment.

Maximum input frequency of 200MHz suitable for high speed applications. Operates from 1.8V to 3.3V supply voltage for various system voltages. Very low pin to pin skew for maintaining signal timing integrity. Integrated serial termination for 50 ohm to reduce signal reflections.

Compact 8-pin TSSOP surface mount package with 3.1mm length and 1mm height. Wide temperature range from -40°C to 105°C for industrial reliability. Synchronous glitch free output enable function for improved output stability.

5PBA series device designed for general semiconductor clock buffering.
