Samtec T1M Series Vertical Surface PCB Header 15 Contact(s) 1 mm Pitch 1 Row Shrouded T1M-15-F-SV-L-P

Free Delivery in India | Lowest Global Shipping Charges

Samtec T1M Series Vertical Surface PCB Header 15 Contact(s) 1 mm Pitch 1 Row Shrouded T1M-15-F-SV-L-P

Name: Samtec T1M Series Vertical Surface PCB Header 15 Contact(s) 1 mm Pitch 1 Row Shrouded T1M-15-F-SV-L-P
Brand: Samtec
SKU: 172182
Price: 2.8 USD
Availability: InStock



Category PCB Headers Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	Samtec
Orientation	Vertical
Current	3.3A
Model	T1M-15-F-SV-L-P
Mount Type	Surface
Housing Material	Natural LCP
Contact Material	Phosphor Bronze
Series	T1M
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-10°C
Number of Rows	1
Pitch	1mm
Contact Plating	Silver, Tin
Number of Contacts	15
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

Ensures reliable wire-to-board connection with 15 male contacts.
Constructed with natural Liquid Crystal Polymer housing for durability.
Contact material is phosphor bronze with silver and tin plating for optimal conductivity.
Designed for surface mount applications with vertical orientation and positive latch.
Suitable for operating temperatures from -10°C to 85°C.
Supports current rating of 3.3A and voltage up to 250V.
Termination type is solder with 1 mm row pitch for precise PCB integration.
Shrouded connector ensures protection and secure mating.

Product Description

Samtec T1M-15-F-SV-L-P is a vertical surface mount PCB header from the T1M series, providing a high-quality connection solution with 15 male contacts arranged in a single row with 1 mm pitch. It features a shrouded housing made of natural Liquid Crystal Polymer (LCP), offering excellent mechanical strength and durability for industrial and electronic applications.

The contacts are made of phosphor bronze material, plated with silver and tin, ensuring reliable electrical conductivity and long-term performance. This connector supports a current rating of 3.3 amperes and a voltage rating of 250 volts, making it suitable for a wide range of electronic circuit board assemblies.

Designed specifically for wire-to-board connections, the T1M-15-F-SV-L-P is vertically oriented with a positive latch mechanism for secure engagement. The solder termination type facilitates a strong mechanical and electrical PCB attachment. Operating temperature ranges from -10°C to +85°C, suitable for various environmental conditions.

This PCB header is ideal for industrial, commercial, manufacturing, and laboratory electronic applications where reliable and compact connection systems are required. The shrouded design helps to protect the contacts from damage and accidental disconnection during use.

The Samtec T1M series connectors are widely recognized for their precision engineering, making them an excellent choice for integration into electronic devices and control systems.

Ensures reliable wire-to-board connection with 15 male contacts. Constructed with natural Liquid Crystal Polymer housing for durability. Contact material is phosphor bronze with silver and tin plating for optimal conductivity.

Designed for surface mount applications with vertical orientation and positive latch. Suitable for operating temperatures from -10°C to 85°C. Supports current rating of 3.3A and voltage up to 250V. Termination type is solder with 1 mm row pitch for precise PCB integration.

Shrouded connector ensures protection and secure mating. Explore more electronic components and connectors designed for high performance and reliability at EnvMart.
