Samtec SMM Series 12-Contact 2-Row 2 mm Pitch Straight Surface PCB Socket SMM-106-02-S-D-P-TR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.2A |
| Model | SMM-106-02-S-D-P-TR |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Beryllium Copper Alloy |
| Series | SMM |
| Termination Type | Surface Mount |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Row Pitch | 1.27mm |
Key Features
- Operates at voltage up to 350V and current of 3.2A.
- Constructed with liquid crystal polymer housing for high durability.
- Features beryllium copper alloy contacts plated with selective gold for reliable conductivity.
- Surface mount termination and straight orientation ensure secure mounting on PCB.
- Supports operating temperatures from -55°C to 125°C for broad environmental use.
- Designed as part of the Samtec SMM series with dual rows of 6 pins per row.
- Contact gender is female, suitable for socket strip applications.
- Compatible with 1.27mm row pitch supporting precise alignment.
Product Description
Samtec SMM-106-02-S-D-P-TR is a straight orientation surface mount PCB socket designed for board-to-board connectivity with 12 contacts arranged in 2 rows and a 2 mm pitch. The product operates reliably at voltages up to 350V and currents of 3.2A, making it suitable for a wide range of electronic applications requiring secure and compact connections.
The housing is made from liquid crystal polymer, providing excellent mechanical strength and thermal stability. Each contact is constructed from beryllium copper alloy and plated selectively with 0.000762 mm gold on the contact area to ensure superior conductivity and corrosion resistance, while the tail features matte tin plating to aid soldering to the PCB. This socket supports surface mount termination with a straight orientation perfect for automated placement and assembly.
The operating temperature range from -55°C to 125°C enables use in diverse industrial, commercial, and electronic manufacturing environments. Its dual row design has 6 pins per row with a 1.27 mm row pitch for accurate installation and integration into complex PCB assemblies. The female contact gender and socket strip subtype provide versatile connectivity options.
Operates at 350V voltage and 3.2A current for robust performance. Liquid crystal polymer housing ensures mechanical and thermal resilience. Beryllium copper alloy contacts with gold plating improve signal integrity and durability.
Surface mount termination with straight orientation facilitates easy PCB mounting. Wide temperature range (-55°C to 125°C) supports harsh environments. Dual row 12-contact design with 2 mm pitch for compact connections. Female contact gender suitable for various board applications.
Packaged via tape and reel enabling efficient automated assembly processes.
This socket is ideal for various electronic manufacturing, industrial equipment assembly, and electronic component prototyping requiring reliable board-to-board connectors. Samtec’s SMM series products are known for precision engineering and quality materials, making them a preferred choice in electronics industry projects.
Explore more in the PCB Sockets category on EnvMart for compatible connectors and related accessories to support your design and production needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates at a maximum voltage of 350V and a current rating of 3.2A.
The housing is constructed from liquid crystal polymer, providing excellent mechanical strength and thermal stability.
It features beryllium copper alloy contacts plated with selective gold for reliable conductivity and corrosion resistance.
The operating temperature range is from -55°C to 125°C, making it suitable for a variety of environments.
This socket has 12 contacts arranged in 2 rows, with a pitch of 2 mm.
It features surface mount termination, which facilitates easy mounting on PCBs.
The SMM-106-02-S-D-P-TR has a straight orientation for secure mounting on the PCB.
This socket has a female contact gender, making it suitable for socket strip applications.
The row pitch for this model is 1.27 mm, allowing for precise alignment during installation.
The country of origin for this product is India.
It is designed as a board-to-board connector system, suitable for various electronic applications.
This socket is packaged via tape and reel, enabling efficient automated assembly processes.
