Samtec SFM Series Straight Surface PCB Socket, 50-Contact, 2 Row, 1.27 mm Pitch, 3.2A, 250V, Liquid SFM-125-02-S-D-LC-K-TR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.2A |
| Model | SFM-125-02-S-D-LC-K-TR |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Beryllium Copper Alloy |
| Series | SFM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | High Reliability Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 50 |
| Contact Gender | Female |
| Connector System | Board-to-Board, Cable |
| Stacking Height | 12mm |
Key Features
- High reliability socket strip designed for surface mount applications.
- Housing made from durable liquid crystal polymer.
- Contact material is beryllium copper alloy with gold plating for excellent conductivity.
- Features a stacking height of 12 mm and straight orientation.
- Operates reliably between temperatures of -55°C to 125°C.
- Compatible with board-to-board and cable connector systems.
- Termination type is solder, ensuring secure connections.
- Includes a locking clip to ensure stability during use.
Product Description
Samtec SFM-125-02-S-D-LC-K-TR is a Straight Surface PCB Socket designed for high-reliability applications in electronics manufacturing. It features 50 contacts arranged in 2 rows with a precise 1.27 mm pitch, supporting electrical currents up to 3.2A at 250 volts. The socket utilizes a liquid crystal polymer housing, which provides excellent mechanical stability and heat resistance, ideal for industrial and commercial electronic assemblies.
The contact areas are plated with selective gold of 0.000762 mm thickness on a beryllium copper alloy base, ensuring low contact resistance and high durability under frequent mating cycles. This model includes a locking clip and polyamide film pick and place pad, enhancing assembly precision and reliability. Designed for surface mounting, the socket is compatible with board-to-board and cable connector systems, supporting various industrial and manufacturing needs.
The operating temperature range from -55°C to 125°C and a stacking height of 12 mm make this PCB socket suitable for harsh environments in industrial electronics, laboratory instrumentation, telecommunications equipment, and high-performance computing devices.
High reliability socket strip designed for surface mount applications. Housing made from durable liquid crystal polymer. Contact material is beryllium copper alloy with gold plating for excellent conductivity. Features a stacking height of 12 mm and straight orientation.
Operates reliably between temperatures of -55°C to 125°C. Compatible with board-to-board and cable connector systems. Termination type is solder, ensuring secure connections. Includes a locking clip to ensure stability during use.
Packaged using tape and reel for automated assembly compatibility.
This PCB socket is essential for precise electronic connector solutions in construction, manufacturing, and laboratory settings. For additional compatible components and related PCB Sockets, explore the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports electrical currents up to 3.2A.
It operates reliably between -55°C and 125°C.
The socket features 50 contacts arranged in 2 rows.
The contact pitch is 1.27 mm.
The housing is made from liquid crystal polymer, and the contacts are beryllium copper alloy with gold plating for conductivity.
It uses a solder termination type, ensuring secure connections.
The stacking height is 12 mm.
Yes, it is compatible with both board-to-board and cable connector systems.
The socket has a straight orientation.
It is packaged using tape and reel for automated assembly compatibility.
The contact gender is female.
The country of origin for this socket is India.
