Abracon 12 MHz Crystal ±30 ppm Surface Mount 4-Pin 5 mm x 3.2 mm x 1.2 mm FC5BQCCMC12.0-T1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Abracon |
| Height | 1.2mm |
| Length | 5mm |
| Model | FC5BQCCMC12.0-T1 |
| Packaging | Tape & Reel |
| Width | 3.2mm |
| Mount Type | Surface |
| Series | FC5BQ |
| Maximum Operating Temperature | 70°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | 0°C |
| Standards/Approvals | RoHS |
| Pin Count | 4 |
| Standard Frequency | 12MHz |
| Load Capacitance | 20pF |
| Fox Electronics 12MHz Crystal ±30ppm SMD 4-Pin 5 x 3.2 x 1.2mmBrand | Fox Electronics |
Key Features
- Standard frequency of 12 MHz for precise oscillation tasks.
- Surface mount type suitable for compact PCB applications.
- Load capacitance rated at 20 pF ensuring accurate frequency control.
- Robust 4-pin package designed for reliable electrical connection.
- Operating temperature range from 0°C to 70°C for stable performance.
- RoHS compliant ensuring environmental safety and lead-free design.
- Packaging provided as Tape and Reel for ease of automated assembly.
- Series FC5BQ features resin seal with silver termination finish.
Product Description
The Abracon FC5BQCCMC12.0-T1 is a high-quality 12 MHz crystal unit designed for surface mount applications. Featuring a 4-pin package measuring 5 mm in length, 3.2 mm in width, and 1.2 mm in height, this crystal ensures precise oscillation with a frequency tolerance and stability of ±30 ppm. It operates reliably within a temperature range of 0°C to 70°C, making it suitable for various industrial and electronic applications.
This crystal delivers a load capacitance of 20 pF and a low shunt capacitance of 5 pF, contributing to stable frequency output with minimal signal loss. The series FC5BQ employs a resin seal and silver termination finish, ensuring durability and excellent solderability on printed circuit boards.
The product is RoHS compliant, adhering to environmental standards and offering a lead-free design. Its surface mount package is supplied in Tape and Reel packaging format, facilitating efficient pick-and-place automated assembly in manufacturing environments.
Typical use cases include applications in industrial electronics, telecommunications, consumer electronics, and embedded systems where stable and accurate timing references are critical.
Standard frequency of 12 MHz for precise oscillation tasks. Surface mount type suitable for compact PCB applications. Load capacitance rated at 20 pF ensuring accurate frequency control. Robust 4-pin package designed for reliable electrical connection.
Operating temperature range from 0°C to 70°C for stable performance. Frequency tolerance and stability of ±30 ppm for consistent output. RoHS compliant ensuring environmental safety and lead-free design. Packaging provided as Tape and Reel for ease of automated assembly.
Series FC5BQ features resin seal with silver termination finish. Shunt capacitance of 5 pF supports optimal electrical characteristics.
Explore the Electronics Components and Crystal Units category at EnvMart for high-quality products like the Abracon FC5BQCCMC12.0-T1 suitable for your electronic design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The standard frequency of this model is 12 MHz, designed for precise oscillation tasks.
This crystal unit has a load capacitance rating of 20 pF, ensuring accurate frequency control.
The dimensions of this model are 5 mm in length, 3.2 mm in width, and 1.2 mm in height.
It operates within a temperature range of 0°C to 70°C, providing stable performance in various environments.
The frequency tolerance and stability of this crystal unit is ±30 ppm, ensuring consistent output.
It is provided in Tape and Reel packaging, facilitating ease of automated assembly in manufacturing environments.
This model utilizes a surface mount type, making it suitable for compact PCB applications.
This crystal unit features a 4-pin package designed for reliable electrical connection.
The shunt capacitance of this model is 5 pF, contributing to optimal electrical characteristics.
Yes, it is RoHS compliant, ensuring environmental safety and a lead-free design.
This model is part of the FC5BQ series, which features a resin seal and silver termination finish.
Typical use cases include industrial electronics, telecommunications, consumer electronics, and embedded systems where stable and accurate timing references are critical.
