Bourns 7045 Shielded Wirewound Surface Mount Inductor Ferrite Core 10 μH 20% Tolerance 2A DC Current SRR7045

Free Delivery in India | Lowest Global Shipping Charges

Bourns 7045 Shielded Wirewound Surface Mount Inductor Ferrite Core 10 μH 20% Tolerance 2A DC Current SRR7045

Name: Bourns 7045 Shielded Wirewound Surface Mount Inductor Ferrite Core 10 μH 20% Tolerance 2A DC Current SRR7045
Brand: BOURNS
SKU: 171356
Price: 0.61 USD
Availability: InStock



Category Inductor Brand BOURNS Condition New

Specifications

Country of Origin	China
Brand	Bourns
Height	7mm
Length	7mm
Model	SRR7045
Depth	4.5mm
Packaging	1000 pieces per Reel
Series	SRR7045
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	10μH
Standards/Approvals	2015, 863, Mar 31, RoHS Directive 2015
Package/Case	7045
Maximum DC Current	2A
Maximum DC Resistance	0.02Ω
Inductance Tolerance	20 %
Termination Style	Cu/Ni/Sn
Maximum Self Resonant Frequency	23MHz
Minimum Quality Factor	40
Inductor Construction	Ferrite Core
Automotive Standard	AEC-Q200

Key Features

Features a shielded wirewound construction for reduced electromagnetic interference.
Ferrite core material provides stability and high inductance performance.
Meets automotive standard AEC-Q200 for reliable operation.
Operating temperature range from -40°C to 125°C for diverse environments.
Maximum DC resistance of 0.02 Ω ensures efficiency.
RoHS compliant with directive 2015 for environmental safety.
Packaged as 1000 pieces per reel suitable for mass production.

Product Description

The Bourns SRR7045 is a shielded wirewound surface mount inductor designed for electronic applications requiring a stable 10 μH inductance with 20% tolerance. It incorporates a ferrite core material that provides strong magnetic properties and minimizes electromagnetic interference, making it ideal for use in sensitive circuits.

Rated for a maximum DC current of 2 A, this inductor supports a wide operating temperature range from -40°C to 125°C, ensuring reliable performance in automotive and industrial environments. Its compact dimensions of 7mm length, 7mm height, and 4.5mm depth make it suitable for space-constrained circuit board designs.

This component complies with the AEC-Q200 automotive standard and the RoHS 2015 directive, ensuring both quality and environmental compliance. The termination style consists of Cu/Ni/Sn plating, ensuring secure solderability and durability.

With a maximum DC resistance of only 0.02 Ω and a minimum quality factor of 40, the SRR7045 supports efficient energy transfer and performance. The maximum self-resonant frequency is 23 MHz, ideal for high-frequency applications.

The product is supplied as a reel of 1000 pieces, facilitating automated assembly processes in electronics manufacturing. This inductor is molded and features a shielded design for enhanced EMC performance.

Shielded wirewound construction reduces electromagnetic interference. Ferrite core material for high inductance and stability. AEC-Q200 automotive standard compliance. Wide operating temperature from -40°C to 125°C. Compact 7 x 7 x 4.5 mm size for surface mount applications.

Maximum DC resistance of 0.02 Ω for efficient operation. RoHS 2015 compliant for environmental safety. Packaged in reel of 1000 pieces for mass production.

This Bourns SRR7045 Inductor is suitable for use in electronic components design, automotive circuits, power supplies, and other industrial and commercial applications. It combines reliability, compactness, and environmental compliance, making it an excellent choice for engineers and manufacturers.

Explore more inductance components and electronic parts in the Bourns range available at EnvMart for your design and production needs.
