Schneider Electric Motor Control Contactor 24V AC Coil, 3-Pole, 6 A, 2.2 kW, 3 NO, 690V AC LC1K06103B7

Schneider Electric LC1K06103B7 is a robust motor control contactor operating with a 24V AC coil voltage, ideal for motor control and resistive load switching in industrial automation and electrical control panels. It features a 3-pole construction with 3 Normally Open (NO) contacts, supporting an operational current of 6 A at contact voltage up to 690V AC. The contactor handles power ratings up to 2.2 kW, making it suitable for diverse industrial applications requiring reliable switching performance.

This device mounts on DIN rails and uses cage clamp terminal types that ensure consistent connection tightness and safety during installation. Its compact size, with dimensions of 45 mm width, 58 mm length, and 57 mm depth, enables efficient space utilization in control cabinets. The contactor is rated for operational temperatures ranging from -25°C up to 50°C, ensuring dependable performance in varying environmental conditions.

The contactor coil has low power consumption at 4.5 VA hold-in and 30 VA inrush, making it energy-efficient. It includes one auxiliary Normally Open (NO) contact, expanding control capabilities for auxiliary circuits. The spring terminals incorporate safety stops to prevent terminal damage from excessive wiring force, enhancing durability and user safety.

Compliance with international standards IEC947-4 EN60947-4-1 and certifications including UL, EAC, IEC, RoHS, CCC, and CSA reflect rigorous quality and safety benchmarks. This product is designed for easy integration with motor circuit breakers like the GV2-M series.

Equipped with 3 poles and 3 Normally Open contacts for reliable switching. Operates at contact voltage of 690V AC with a contact current rating of 6 A. Power rating is 2.2 kW suitable for various industrial control tasks.

Mounts easily on DIN rail with cage clamp terminal type for secure wiring. Includes 1 Normally Open auxiliary contact for additional control functions. Designed to operate reliably from -25°C to 50°C ambient temperatures.

Conforms to IEC947-4 EN60947-4-1 standards with approvals including UL, EAC, IEC, RoHS, CCC, and CSA. Compact dimensions: Width 45 mm, Length 58 mm, Depth 57 mm for efficient panel mounting. Features spring terminals with safety stops preventing terminal damage during wiring.

Energy-efficient coil consumption with 4.5VA hold-in and 30VA inrush current.

This Schneider Electric contactor is essential for industrial automation, electrical control gear, motor control, HVAC systems, manufacturing lines, and similar commercial or industrial applications. It supports reliable switching and control of electric motors and resistive loads, meeting stringent safety and efficiency standards.
