Kopp xPole Miniature Circuit Breaker 3-Pole 16A Type C 400V AC 48V DC 10 kA Breaking Capacity 236426 PXL-C16/3

Eaton 236426 PXL-C16/3 xPole Miniature Circuit Breaker is a robust 3-pole device rated for 16 amperes, designed to protect electrical circuits from overcurrents and short circuits in residential, commercial, and light industrial environments.

Operating at 400 volts AC and 48 volts DC, it combines high breaking capacity of 10 kA with type C electromagnetic tripping characteristics, accommodating the initial inrush currents typical of inductive loads such as motors and transformers. The circuit breaker features a compact and space-saving design with dimensions 80 mm (width) x 52.5 mm (height) x 60 mm (depth) and mounts easily onto a standard DIN rail system.

Equipped with a toggle switch reset actuator, it allows straightforward manual resetting post-tripping events. Its IP20 rating provides protection against solid objects larger than 12 mm. The breaker is engineered for thermal stability, maintaining operational reliability across temperatures ranging from -25°C to 55°C.

Compliance with IEC and EN 60898 standards ensures high safety and quality benchmarks. The device facilitates use with multi-wired conductors up to 25 mm² cross-sectional area, offering versatile installation options.

This Eaton MCB is ideal for integration in residential switchgear, commercial electrical distribution panels, industrial automation control panels, and motor protection circuits. Rated for 400V AC and 48V DC electrical systems.

Type C characteristic prevents nuisance trips with inductive loads. 10 kA high breaking capacity ensures robust fault interruption. Compact design supports efficient space utilization on DIN rails. Toggle switch actuator for easy reset and operation.

IP20 ingress protection rating. Thermally stable performance across temperature ranges. Standards certified under IEC and EN 60898. Explore the Eaton xPole range for reliable circuit protection solutions on EnvMart.
