SMC Pneumatic Compact Cylinder 25mm Bore, 10 mm Stroke, Single Acting, Aluminium Alloy CQ2B25-10S

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Compact Cylinder 25mm Bore, 10 mm Stroke, Single Acting, Aluminium Alloy CQ2B25-10S



Category Pneumatic Cylinder Brand SMC Condition New

Specifications

Country of Origin	China
Brand	SMC
Body Material	Aluminium Alloy
Maximum Operating Pressure	1.5 Mpa
Height	40mm
Length	37.5mm
Model	CQ2B25-10S
Gross Weight	101g
Width	40mm
Mount Type	Through Hole
Series	CQ2
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-10°C
Stroke Length	10mm
Bore Diameter	25mm
Rod Type	Single
Action Type	Single Acting
Piston Rod Gender	Female
Piston Rod Thread Standard	Metric

Key Features

Compact size with 37.5mm length and 40mm height and width for space saving installation.
Single acting operation suitable for controlled pneumatic actuation.
Maximum operating pressure of 1.5 MPa ensures reliable performance.
Operating temperature range from -10°C to 70°C for versatile environmental conditions.
Through hole mount type with metric internal female threaded rod end for convenient assembly.
Constructed from durable aluminium alloy body for lightweight and corrosion resistance.
Maximum piston speed of 500mm/s supports rapid actuation cycles.
Supplied with nitrile seals and does not require lubrication during operation.

Product Description

SMC CQ2B25-10S pneumatic compact cylinder features a 25mm bore diameter and 10 mm stroke length in a single acting configuration. This cylinder is constructed from robust aluminium alloy to reduce weight while maintaining durability, providing a compact alternative to traditional tie rod cylinders. It measures 37.5mm in length, with 40mm width and height, making it suitable for installations where space is limited.

The cylinder operates reliably under maximum pressure of 1.5 MPa with a maximum piston speed of 500mm/s. It functions effectively in temperatures from -10°C up to 70°C, allowing versatility in various industrial environments. The through hole mount type and metric internal female threaded rod end permit straightforward mounting and integration into pneumatic systems.

Additional design advantages include a magnetic piston for compatibility with solid state switches, nitrile seals that eliminate the need for lubrication, and tapered and parallel ports for flexible connection options. This compact cylinder is ideal for industrial automation, manufacturing processes, material handling, and other applications requiring precise pneumatic actuation in a space-saving design.

Compact size with 37.5 mm length and 40 mm width and height provides space and weight savings. Single acting pneumatic operation for controlled linear motion. Maximum operating pressure of 1.5 MPa ensures dependable performance.

Operating temperature range from -10°C to 70°C suits diverse environments. Through hole mounting and internal female metric threaded rod ends for easy installation. Aluminium alloy construction offers durability and corrosion resistance.

Maximum piston speed of 500 mm/s for fast actuation cycles. Magnetic piston compatible with solid state sensors for position detection. Nitrile seals eliminate lubrication requirements, reducing maintenance. Ideal for industrial, manufacturing, automation, and pneumatic applications.
