Samtec PCB Socket Vertical Through Hole, 22-Contact, 2 Row, 2.54 mm Pitch, Solder Termination IPS1

The Samtec IPS1 Series PCB Socket is a high-quality vertical through-hole connector designed to provide reliable connection solutions for electronic circuit boards. Featuring 22 contacts arranged in 2 rows with a 2.54 mm pitch, this socket facilitates robust board-to-board electrical interfaces through solder termination.

Its housing is crafted from liquid crystal polymer, offering excellent durability, heat resistance, and electrical insulation, making it suitable for demanding industrial applications. The phosphor bronze, gold-plated contacts ensure exceptional conductivity and corrosion resistance, maintaining signal integrity even under challenging environmental conditions.

Rated for voltages up to 1095 V AC and a current capacity of 4.8 A at 95°C, the IPS1 socket is designed to operate within temperature extremes from -55°C to 125°C, accommodating various industrial, manufacturing, and electronic device conditions.

This connector supports through-hole mounting with vertical orientation and includes individually shrouded contacts to prevent short circuits. The optional locking clip enhances mechanical stability in assemblies where vibration or mechanical stress might occur.

The Samtec IPS1 is RoHS compliant, ensuring it meets environmental standards for hazardous substance reduction. Its design makes it well suited for industrial electronics, telecommunications, automation, and other professional applications requiring consistent, high-performance PCB connections.

This PCB socket features a 2-row configuration with a 2.54 mm pitch for precise board-to-board connections. Constructed with liquid crystal polymer housing ensuring high durability and electrical insulation. Contacts are made of phosphor bronze plated with gold over nickel to maintain conductivity and prevent corrosion.

Supports operating voltages up to 1095 V AC with a current rating of 4.8 A at 95°C for reliable performance. Designed for through-hole mounting, enabling vertical orientation to facilitate PCB assembly. Capable of operating between -55°C and 125°C, suitable for a wide range of industrial environments.

The socket includes individually shrouded contacts with an optional locking clip for secure connections. Compliant with RoHS standards, ensuring environmental safety and regulatory adherence. Ideal for applications requiring high-quality PCB connections in electronics, manufacturing, and industrial assemblies.

The connector system supports board-to-board interfacing with enhanced mechanical stability. Explore a wide range of PCB Sockets and connectors at EnvMart designed for industrial and commercial electronics manufacturing applications.
