Samtec PCB Socket 40-Contact 2 Row 2.54 mm Pitch Through Hole Right Angle Solder Termination IPS1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 4.8A |
| Model | IPS1 |
| Mount Type | Through Hole |
| Series | IPS1 |
| Termination Type | Solder |
| Sub Type | Socket |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 40 |
| Connector System | Board-to-Board |
Key Features
- Features 40 gold-plated contacts arranged in dual rows for reliable conductivity.
- Maintains a 2.54 mm pitch to ensure precise board compatibility.
- Supports up to 4.8 A current at elevated temperature for stable power delivery.
- Right-angle through-hole mount for optimized PCB layout and mechanical strength.
- Individually shrouded contacts to reduce short circuit risk.
- Optional locking clip enhances connection security.
- Suitable for industrial, laboratory, electronic manufacturing, and telecommunications use.
Product Description
Samtec IPS1 PCB Socket model IPS1-120-01-L-D is a high-quality electronic component designed for right-angle through-hole mounting on printed circuit boards. It features 40 gold-plated contacts arranged in two rows with a uniform 2.54 mm pitch, ensuring precise and reliable board-to-board connections in demanding industrial, manufacturing, and electronic equipment applications.
This PCB socket supports a continuous current of 4.8 A at 95°C, making it suitable for circuits that require stable and robust power delivery. The individually shrouded contacts prevent electrical shorts and enhance durability. The solder termination type provides secure mechanical and electrical connection integrity, while the right-angle orientation optimizes board layout and space utilization.
The socket includes an optional locking clip that helps secure mated connectors, reducing the risk of accidental disconnection in industrial or laboratory environments. It complies with the IPS1 series standards and is designed to be compatible with a broad range of board-to-board connector systems, ensuring flexibility in complex electronic design.
Applications for this PCB Socket include electronic manufacturing, industrial automation equipment, telecommunications, instrumentation, and any setting that demands reliable electrical interconnections with a robust current rating. Its through-hole mount construction ensures strong physical attachment on PCBs subjected to mechanical stress or vibration.
Features 40 gold-plated contacts arranged in dual rows for reliable conductivity. Maintains a 2.54 mm pitch to ensure precise board compatibility. Supports up to 4.8 A current at elevated temperature for stable power delivery.
Right-angle through-hole mount for optimized PCB layout and mechanical strength. Individually shrouded contacts to reduce short circuit risk. Optional locking clip enhances connection security. Suitable for industrial, laboratory, electronic manufacturing, and telecommunications use.
Explore more in our Electronics Components category at EnvMart for comprehensive board-to-board connector solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a continuous current of 4.8 A at 95°C, providing stable power delivery for various applications.
The contacts are arranged with a uniform pitch of 2.54 mm, ensuring precise compatibility with printed circuit boards.
It features 40 gold-plated contacts arranged in dual rows, which enhances conductivity and reliability in connections.
It utilizes a solder termination type, which provides secure mechanical and electrical connection integrity.
This model is designed for through-hole mounting, ensuring strong physical attachment on PCBs.
The contacts are arranged in a right-angle orientation, optimizing PCB layout and mechanical strength.
It is suitable for use in industrial automation, electronic manufacturing, telecommunications, and instrumentation applications.
Individually shrouded contacts help reduce the risk of electrical shorts and enhance the durability of the connections.
Yes, it includes an optional locking clip that helps secure mated connectors, reducing the risk of accidental disconnection.
The IPS1 PCB socket is manufactured in India.
It is designed for board-to-board connector systems, ensuring flexibility in complex electronic designs.
The right-angle design optimizes the layout and space utilization on printed circuit boards, making it advantageous for various applications.
