Samtec TSW Series Straight Through Hole Pin Header, 13 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSW-113-07-T-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-113-07-T-S |
| Mount Type | Through Hole |
| Special Features | Many options fo |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 13 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Features 13 male contacts configured in a single row for versatile use.
- 2.54 mm pitch guarantees compatibility with standard PCB layouts.
- Constructed with a glass filled polyester housing ensuring durability.
- Contact plating in gold over phosphor bronze ensures reliable conductivity and corrosion resistance.
- Supports a maximum operating temperature of 125°C and a minimum of -55°C.
- Designed for through hole mounting with solder termination for robust mechanical connection.
- Suitable for industrial electronic component applications requiring high electrical reliability.
Product Description
Samtec brand TSW Series Pin Header model TSW-113-07-T-S is a straight, through-hole mount, unshrouded connector featuring 13 male contacts arranged in a single row with a 2.54 mm pitch. The housing is made from glass filled polyester, delivering high mechanical strength and electrical insulation resistance. Contacts are composed of phosphor bronze with gold plating for excellent conductivity and durability, making this header ideal for high-reliability board-to-board connector systems.
Operating temperature ranges from -55°C to a maximum of 125°C, suitable for a variety of industrial environments. The header supports up to 550 volts, providing secure electrical performance. Its solder termination type ensures a strong and permanent connection on printed circuit boards designed for through-hole mount components.
This connector is commonly used in electronics manufacturing, industrial automation, and power distribution applications requiring standard pin counts and pitch for component compatibility and easy integration.
13 male contacts in one row for versatile pin configurations. 2.54 mm pitch for industry standard spacing and compatibility. Durable glass filled polyester housing. Gold-plated phosphor bronze contacts for reliability and corrosion resistance.
Wide operating temperature range of -55°C to 125°C. Solder termination type ensuring robust mechanical and electrical connection. Rated voltage of 550V suitable for various industrial scenarios.
This pin header belongs to the PCB Pin Header category, an essential component for PCB assembly, electronics repair, and prototyping in industrial, manufacturing, and laboratory settings. Explore more from Samtec connectors on EnvMart for your precision electronics projects.
