Samtec TSW Series Straight Through Hole Pin Header, 100 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-150-17-L-D

Free Delivery in India | Lowest Global Shipping Charges

Samtec TSW Series Straight Through Hole Pin Header, 100 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-150-17-L-D

Name: Samtec TSW Series Straight Through Hole Pin Header, 100 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-150-17-L-D
Brand: Samtec
SKU: 130490
Price: 8.08 USD
Availability: InStock



Category PCB Headers Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	550V
Brand	Samtec
Orientation	Straight
Current	7.6A
Model	TSW-150-17-L-D
Mount Type	Through Hole
Housing Material	Glass Filled Polyester
Contact Material	Phosphor Bronze
Series	TSW
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	100
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board, Wire-to-Board
Tail Pin Length	2.79mm
Mating Pin Length	15.75mm

Key Features

Constructed with glass filled polyester housing for durability.
Phosphor bronze contacts plated with gold ensure reliable conductivity.
Compatible with board-to-board and wire-to-board connector systems.
Operates efficiently between -55°C to 125°C temperature range.
Rated for a current of 7.6A and voltage up to 550V.
Through hole mount type with solder termination offers secure PCB connection.
Tail pin length of 2.79 mm and mating pin length of 15.75 mm.
Unshrouded design allows easy access and mating with standard sockets.

Product Description

Samtec TSW-150-17-L-D is a high-performance PCB pin header from the TSW series designed for through hole mounting applications requiring reliable connection in electronic assemblies.

This pin header features 100 male contacts arranged in 2 rows with a 2.54 mm pitch. The housing is made from rugged glass filled polyester, providing excellent insulation and mechanical stability.

Contacts are fabricated from phosphor bronze and plated with gold plating to ensure superior conductivity and resistance to corrosion, operating reliably within a temperature range from -55°C to 125°C. The connector system supports both board-to-board and wire-to-board configurations, making it versatile for various industrial, laboratory, and manufacturing uses.

Designed for solder termination with a tail pin length of 2.79 mm, the part also provides a mating pin length of 15.75 mm, suitable for secure and durable electrical connections. Rated at 7.6A current and 550V voltage, it meets the needs of demanding electronic components requiring stable power delivery.

Its unshrouded, straight orientation allows compatibility with standard socket types such as BCS box sockets and CES low profile socket strips, enhancing design flexibility. Built with glass filled polyester housing for durability and insulation.

Features phosphor bronze contacts with gold plating for performance. Supports board-to-board and wire-to-board connector applications. Operates within a wide temperature range of -55°C to 125°C. Rated for 7.6A current and 550V voltage compliance.

Through hole solder termination ensures stable mounting on PCBs. Unshrouded 2-row design with 2.54 mm pitch optimizes connectivity.

This pin header is suitable for electronics manufacturing, industrial equipment assembly, laboratory and test setups requiring robust electrical connections. Its compatibility with a variety of sockets and mounting configurations makes it an essential component for PCB connector solutions.

Explore more products in our PCB Headers category.
