Samtec SSW Series Straight Through Hole Female PCB Socket, 4 Contacts, 2 Rows, 2.54 mm Pitch, Solder SSW-102-01-S-D

The Samtec SSW-102-01-S-D is a precision-engineered female PCB socket from the renowned SSW Series, designed for straight through hole mounting. It features 4 contacts arranged in 2 rows with a 2.54 mm pitch, optimized for board-to-board connectivity. The housing is made from liquid crystal polymer, providing robust thermal resistance and long-term reliability in demanding environments.

The phosphor bronze contacts are plated with gold to ensure excellent conductivity and corrosion resistance. Each contact supports a current load of up to 4.7 A and can safely operate at voltages up to 655 V, making this socket suitable for various industrial and electronic applications.

Operating temperature ranges from -55°C to 125°C allow for reliable performance in harsh and variable conditions. The contact design incorporates both standard and low insertion force options, facilitating easier solder tail mounting and maintenance while maintaining secure electrical connections.

This PCB socket is ideally suited for use in electronic manufacturing, industrial equipment assembly, and laboratory equipment requiring reliable board-to-board connectors with through hole solder mounting.

Robust current rating of 4.7 A per contact ensures dependable electrical performance. High-quality liquid crystal polymer housing offers thermal stability. Phosphor bronze contacts with gold plating reduce resistance and prevent corrosion.

Designed for through hole mounting with solder termination and straight orientation. Wide operating temperature from -55°C to 125°C. Voltage withstand up to 655 V suitable for various industrial applications. Standard and low insertion force contact options for easy assembly.

Supports board-to-board connector system integration.

Environmentally robust and technical specification-rich, this Samtec SSW series PCB socket meets the requirements of diverse electronic components and connector needs in construction, manufacturing, and laboratory contexts. For further component options and detailed models, explore the PCB Socket category on EnvMart to find compatible and related products.
