Samtec SSQ Series Straight Through Hole PCB Socket 20-Contact 2 Row 2.54 mm Pitch SSQ-110-21-G-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 655V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 6.3A |
| Model | SSQ-110-21-G-D |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | SSQ |
| Termination Type | Through Hole |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Row Pitch | 2.5mm |
Key Features
- Features a liquid crystal polymer housing for durability and heat resistance.
- Includes phosphor bronze female contacts with 0.51 µm gold plating for reliable conductivity.
- Rated for 6.3 amps current and 655 volts voltage for robust electrical performance.
- Designed for a straight orientation and square tail for easy self-nesting during assembly.
- Operates reliably within a temperature range of -55°C to 125°C for varied environments.
- Offers a row pitch of 2.5 mm ensuring precise alignment in applications.
- No certifications are listed, suitable for industrial, electronic, and manufacturing use.
- Compatible with board-to-board connector systems requiring through-hole mounting.
Product Description
Samtec SSQ-110-21-G-D is a precision-engineered straight through hole PCB socket featuring 20 contacts arranged in 2 rows with a 2.54 mm pitch. It is manufactured with a robust liquid crystal polymer housing ensuring mechanical stability and thermal resistance essential for demanding electronic applications.
The socket's phosphor bronze female contacts are plated with gold at 0.51 microns thickness, providing excellent corrosion resistance and low contact resistance, critical for signal integrity and long service life.
This PCB socket supports a current rating of 6.3 A and a voltage rating of up to 655 V, making it suitable for a wide range of industrial, laboratory, and electronic manufacturing processes requiring reliable board-to-board connection solutions.
The through hole termination type with square tail design simplifies installation and ensures secure mounting. With operation temperature limits from -55°C to 125°C, this connector is viable for harsh environments including outdoor and high-temperature scenarios.
The product is ideal for applications in electronics manufacturing, industrial equipment assembly, aerospace, and automotive electronics where durable, high-reliability interconnects are mandatory.
Liquid crystal polymer housing for heat and chemical resistance. Phosphor bronze contacts with gold plating for enhanced conductivity. 20 contact points across 2 rows at 2.54 mm pitch for compact layouts. Supports up to 6.3 A current and 655 V voltage rating for demanding circuits.
Operating temperature from -55°C to 125°C for extended application environments. Through hole mount with square tail for robust mechanical stability. Straight orientation designed for board-to-board connection systems. Series: SSQ, ensuring compatibility within Samtec connector ranges.
This Samtec SSQ series PCB socket meets industrial standards and offers dependable performance for PCB connection needs. Explore more PCB Sockets in the Electronics Components category at EnvMart to suit diverse industrial and electronic requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 6.3 A and a voltage rating of up to 655 V, making it suitable for demanding electrical applications.
The socket features a pitch of 2.54 mm and includes 20 contacts arranged in 2 rows, allowing for compact layouts in PCB designs.
The housing is made from liquid crystal polymer, which provides durability and heat resistance for reliable performance in various environments.
It utilizes a through hole termination type, which simplifies installation and ensures secure mounting on the PCB.
This socket operates reliably within a temperature range of -55°C to 125°C, making it suitable for harsh environmental conditions.
The contacts are made of phosphor bronze and are plated with 0.51 µm of gold, providing excellent conductivity and corrosion resistance.
This model is designed with a straight orientation, facilitating easy self-nesting during assembly for board-to-board connections.
Yes, it is compatible with board-to-board connector systems that require through-hole mounting, suitable for various applications.
The sub-type classification of this model is a socket strip, which is typically used for board-to-board connections in electronic applications.
The socket features 20 contacts arranged in 2 rows with a pitch of 2.54 mm, designed for precise alignment in PCB applications.
This socket is suitable for applications in electronics manufacturing, industrial equipment assembly, aerospace, and automotive electronics, where reliable interconnects are essential.
No specific certifications are listed for this model, but it is designed for industrial, electronic, and manufacturing use.
