HARWIN Datamate L-Tek Series Straight Through Hole PCB Header, 5 Contacts, 2 mm Pitch, 1 Row, Shrouded M80-8820542

HARWIN M80-8820542 Datamate L-Tek Series Straight Through Hole PCB Header is a rugged, high-reliability electronic connector designed primarily for industrial and commercial electronic applications demanding secure board-to-board and wire-to-board connections. It is a shrouded, single-rank connector with 5 gold-plated phosphor bronze contacts spaced at 2 mm pitch, optimized for through-hole solder mounting.

The housing is constructed from polyphenylene sulphide, delivering excellent chemical and thermal resistance, critical for operation in harsh environments. The 3A current rating and 120V voltage rating make it suitable for low power, signal, and control circuitry in demanding industrial, aerospace, military, automotive, and telecommunications systems.

These connectors utilize high-reliability four-finger beryllium copper contacts that maintain superior connection integrity even under high vibration, shock, and accelerated wear due to frequent mating cycles. The connector is polarized through its shrouded design and offers a tail pin length of 3 mm, ensuring secure and robust solder joints for stable electrical and mechanical performance.

Operating across a broad temperature range from -55°C to 125°C, this connector is suited for use in extreme conditions. It complies with stringent standards including BS9525-F0033, MIL C 55302, and CEC 75101-008 that validate its industrial and military-grade quality.

Typical application areas include industrial manufacturing equipment, aerospace electronic interfaces, defense systems, telecommunications hardware, and automotive electronic assemblies requiring reliable, durable connectors.

The connector features phosphor bronze contacts plated with gold for high reliability. Housing material is durable polyphenylene sulphide suitable for harsh environments. It supports a current rating of 3 amps and operates up to 120 volts.

Designed for through-hole mounting, providing robust mechanical retention. Operating temperature range spans from -55°C to 125°C. Tail pins have a length of 3 mm enabling secure solder termination. The connector is shrouded and straight oriented to ensure polarized mating and electrical safety.

Highly durable four-finger beryllium copper contacts ensure reliable connection under vibration and shock conditions. Complies with military and industry standards BS9525-F0033, MIL C 55302, and CEC 75101-008. This product is manufactured in the United Kingdom and distributed for use in various industrial and commercial electronics applications.
