HARWIN M80 Series Straight Through Hole 4-Contact 1 Row 2 mm Pitch Solder PCB Socket M80-8400445

HARWIN M80-8400445 is a precision-engineered PCB socket featuring a 4-contact, single-row design with a 2 mm pitch for through-hole solder mounting. This connector is part of the renowned M80 Datamate series, known for its robustness and reliability in demanding electronic applications. It incorporates a nylon housing that provides excellent mechanical strength and durability.

The socket supports a current rating of 12A and is rated for 120V, making it suitable for a wide range of electronics, industrial, and commercial uses. The contact material is a beryllium copper alloy, chosen for its excellent electrical conductivity and mechanical resilience. The contacts are gold-plated to ensure superior corrosion resistance and consistent signal integrity over many mating cycles.

Designed for harsh environments and high vibration applications, the M80 series features four-finger contact clips that maintain connection integrity even under severe mechanical stress. The connector includes polarised mouldings to prevent assembly errors and facilitate fast and correct installation.

Operating temperature specifications from -55°C up to 125°C allow this PCB socket to perform reliably in extreme environments such as industrial machinery, automotive electronics, aerospace, and other rugged embedded systems.

Durable nylon housing provides mechanical stability and longevity. Four-finger beryllium copper contacts with gold plating for high reliability. The 2 mm pitch and single row design suit compact PCB layouts. Polarised mouldings ensure correct and secure mating with counterpart connectors.

Compatible with standard L-Tek SIL male headers, enhancing system interoperability. Meets industry standards including BS9525-F0033, MIL C 55302, and CEC 75101-008. Manufactured in the UK, guaranteeing high production quality.

This PCB socket is ideal for industrial, laboratory, automotive, and consumer electronics where durability, high current rating, and reliability are critical. It facilitates modular designs in electronic assemblies, easing maintenance and upgrade processes.
