| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 2.6mm |
| Length | 4.8mm |
| Model | BZV85-C30,113 |
| Mount Type | Through Hole |
| Series | BZV85 |
| Maximum Operating Temperature | 200°C |
| Package Type | DO-41 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 1.3W |
| Diode Configuration | Single |
| Test Current It | 8mA |
| Maximum Reverse Leakage Current | 50nA |
| Nominal Zener Voltage Vz | 30V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 45Ω |
| Typical Voltage Temperature Coefficient | 27.2mV/°C |
Nexperia BZV85-C30,113 Zener Diode is a reliable discrete semiconductor designed for voltage regulation in electronic circuits. With a nominal Zener voltage of 30V and power dissipation of 1.3W, this device suits various industrial, laboratory, and electronic applications requiring stable voltage references.
This diode uses a single configuration and comes in a through hole mount with a 2-pin DO-41 package, making it compatible with standard PCB assembly processes. The device features a voltage tolerance of ±5%, ensuring precise regulation within operating parameters.
Engineered to operate at temperatures from -65°C up to 200°C, it is suitable for harsh environmental conditions and extended use. Its test current of 8mA and low reverse leakage current of 50nA contribute to energy efficiency in sensitive equipment.
The maximum Zener impedance of 45Ω maintains voltage stability during operation, which is critical for performance consistency. Its compact length of 4.8mm and height of 2.6mm allow integration into space-constrained designs.
This BZV85 series diode is ideal for use in power supplies, voltage regulators, voltage clamping, and protection circuits. It serves well in industrial controls, automotive electronics, instrumentation, and other semiconductor applications requiring robust voltage regulation.
The diode features a single configuration for precise voltage regulation. Designed with a through hole mount and 2-pin DO-41 package for easy PCB integration. Offers a voltage tolerance of ±5% ensuring stable performance under specified conditions.
Operates reliably within a temperature range of -65°C to 200°C suitable for industrial environments. Test current is 8mA with a maximum reverse leakage current of 50nA for minimal power loss. The maximum Zener impedance is 45Ω to maintain voltage regulation accuracy.
Compact dimensions: 4.8mm length and 2.6mm height for space-saving applications. Typical voltage temperature coefficient of 27.2mV/°C to account for thermal variations. Explore more semiconductor and diode products in the Electronics & Electricals category at EnvMart for your projects and industrial needs.
