Nexperia Zener Diode 3.6 V 500 mW Single Surface Mount 2-Pin SOD-80 BZV55-C3V6,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Zener Diode 3.6 V 500 mW Single Surface Mount 2-Pin SOD-80 BZV55-C3V6,115

Name: Nexperia Zener Diode 3.6 V 500 mW Single Surface Mount 2-Pin SOD-80 BZV55-C3V6,115
Brand: Nexperia
SKU: 164553
Price: 0.04 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1.6mm
Length	3.7mm
Model	BZV55-C3V6,115
Mount Type	Surface
Series	BZV55
Maximum Operating Temperature	200°C
Package Type	SOD-80
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	5μA
Nominal Zener Voltage Vz	3.6V
Zener Type	Voltage Regulator
Maximum Zener Impedance	90Ω
Typical Voltage Temperature Coefficient	-2.4mV/°C

Key Features

This diode is configured with two pins in a compact SOD-80 package suitable for surface mounting.
It features a nominal Zener voltage of 3.6 V with a tolerance of ±5% ensuring stable voltage regulation.
The device operates safely within a temperature range from -65°C to 200°C.
Maximum power dissipation is 500 mW, supporting reliable performance in electronic circuits.
It has a test current of 5 mA and a maximum Zener impedance of 90 ohms.
Maximum reverse leakage current is limited to 5 μA to reduce losses when reverse biased.
The diode's typical voltage temperature coefficient is -2.4 mV/°C, important for thermal performance analysis.
Designed without automotive standards certification and no approvals or special certifications indicated.

Product Description

Nexperia BZV55-C3V6,115 Zener Diode is a 3.6 V, 500 mW single-element voltage regulator diode designed for surface mount applications. It comes in a compact 2-pin SOD-80 package suited for diverse electronic circuit board designs.

This diode operates within a broad temperature range of -65°C to 200°C, allowing it to perform reliably under various industrial, laboratory, and electronic manufacturing conditions. It delivers a nominal Zener voltage of 3.6 V with a ±5% tolerance, providing steady voltage regulation for power supply stabilization and protection circuit applications.

With a maximum power dissipation of 500 milliwatts, the BZV55 series diode offers sufficient capacity for low power electronics and instrumentation uses. The diode’s test current is 5 mA and features a maximum Zener impedance of 90 ohms, ensuring precision in voltage clamping and regulation tasks.

Its maximum reverse leakage current of 5 microamperes minimizes energy loss and maintains device efficiency. The typical voltage temperature coefficient of -2.4 mV/°C must be considered for temperature-dependent voltage changes, essential in sensitive circuit designs.

Physical dimensions of 1.6 mm height and 3.7 mm length enable compact assembly on printed circuit boards while preserving high performance. This component is intended for industrial electronics, laboratory equipment, manufacturing control systems, and power management applications.

This Zener diode is built to be surface mounted with a two-pin SOD-80 package, facilitating easy integration. Ideal for voltage regulation, reference voltage generation, and protecting circuits from voltage surges. Operates effectively within wide temperature extremes, suitable for harsh environments.

Provides low leakage current characteristics to enhance circuit reliability. Used widely in electronics manufacturing, testing equipment, and embedded system boards.
