Nexperia Zener Diode Single 18 V 250 mW Surface Mount SOT-23 3-Pin BZX84-C18,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Zener Diode Single 18 V 250 mW Surface Mount SOT-23 3-Pin BZX84-C18,215

Name: Nexperia Zener Diode Single 18 V 250 mW Surface Mount SOT-23 3-Pin BZX84-C18,215
Brand: Nexperia
SKU: 164525
Price: 0.04 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1.1mm
Length	3mm
Model	BZX84-C18,215
Mount Type	Surface
Series	BZX84
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Pin Count	3
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	250mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	50nA
Nominal Zener Voltage Vz	18V
Zener Type	Voltage Regulator
Maximum Zener Impedance	45Ω
Typical Voltage Temperature Coefficient	14.4mV/°C
onsemi 1, 18 V Zener Diode, Single 300 mW 5 % Surface 3-Pin SOT-23Brand	onsemi

Key Features

This diode features a single element per chip for stable and precise operation.
The device supports a maximum operating temperature of 150°C and minimum of -65°C.
Its Zener voltage tolerance is ±5% with a typical voltage temperature coefficient of 14.4 mV/°C.
The package has 3 pins and measures 3 mm in length and 1.1 mm in height.
Designed as a voltage regulator Zener diode, ideal for various electronic circuits and applications.
Maximum reverse leakage current is limited to 50 nA to ensure minimal loss.
Maximum Zener impedance is 45 Ω at test current 5 mA for consistent performance.
Automotive grade compliant with AEC-Q101 standard for stringent quality and reliability.

Product Description

Nexperia BZX84-C18,215 is a high-performance Zener diode designed for voltage regulation with a nominal Zener voltage of 18 V and power dissipation capability of 250 mW. It comes in a compact SOT-23 surface mount package with 3 pins, making it suitable for densely packed electronic circuits and devices.

This single element Zener diode is perfect for protecting sensitive components by providing voltage stabilization in a wide temperature range from -65°C to 150°C. Its Zener voltage tolerance of ±5% ensures precise voltage regulation under varying operating conditions.

The device features a maximum reverse leakage current of 50 nA, minimizing power loss and heat generation. The typical voltage temperature coefficient of 14.4 mV/°C further enhances its stability across temperature fluctuations. It meets the automotive standard AEC-Q101, ensuring robust performance and reliability in demanding environments.

The diode's small physical dimensions of 3 mm length and 1.1 mm height allow easy integration into PCB designs, making it ideal for industrial, automotive, electronics manufacturing, and other high-reliability applications.

This diode features a single element per chip for stable and precise operation. Maximum operating temperature is rated at 150°C with minimum down to -65°C. Zener voltage tolerance is ±5% for accurate voltage clamping. Package type is SOT-23 surface mount with 3 pins for compact PCB footprint.

Maximum power dissipation of 250 mW suits low-power voltage regulation needs. Compliance with AEC-Q101 automotive standard ensures quality and durability. Maximum reverse leakage current limited to 50 nA reduces power waste.

Typical voltage temperature coefficient of 14.4 mV/°C for temperature stability.

Choose the Nexperia BZX84-C18,215 Zener Diode for efficient and reliable voltage regulation in electronic circuits across industrial, automotive, and manufacturing sectors. Explore more semiconductor and electronic components at EnvMart for your prototyping and production needs.
