Samtec SMH Series Straight Surface Mount PCB Socket, 8-Contact, 1 Row, 2.54 mm Pitch Solder SMH-108-02-L-S
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Model | SMH-108-02-L-S |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | SMH |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Surface Mount Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- The socket utilizes Liquid Crystal Polymer housing for enhanced durability.
- Phosphor bronze contacts are plated with gold for reliable conductivity.
- Designed for board-to-board connector systems.
- Operates reliably in temperatures ranging from -55°C to +125°C.
- It is RoHS compliant ensuring environmentally safe usage.
- Ideal for industrial and electronic component assembly applications.
- Features solder termination for surface mounting on PCBs.
- Compact single-row design supports 8 contact points.
Product Description
Samtec SMH-108-02-L-S is a professional-grade straight surface mount PCB socket designed with 8 female contacts arranged in a single row at a 2.54 mm pitch. It features a robust Liquid Crystal Polymer (LCP) housing that delivers excellent insulation and durability for demanding electronic applications. The contacts are made from phosphor bronze and plated with gold to ensure superior electrical conductivity and corrosion resistance.
This socket is intended for use in board-to-board connector systems where reliable solder termination and stable mechanical connection are required. It supports operation in a wide temperature range from -55°C to +125°C, making it suitable for various industrial, manufacturing, and electronics assembly environments.
The SMH series socket is RoHS compliant, adhering to environmental standards for hazardous substance limitation. Its single-row, 8-contact configuration ensures compactness while delivering robust electrical connectivity, ideal for LED drivers, communication devices, and control systems.
The solder termination mount type facilitates secure attachment to PCB surfaces, providing consistent performance during soldering and operation. The straight orientation and board-to-board connector system simplify integration into existing PCB designs.
The socket strip uses high-quality Liquid Crystal Polymer housing for insulation and strength. Phosphor bronze contact parts are gold plated to maintain conductivity and resist oxidation. The component is certified RoHS compliant for environmentally friendly application.
Designed for industrial, manufacturing, and commercial electronics uses including prototyping and production boards. The operating temperature range ensures reliability under extreme conditions. 8-contact, single-row design supports compact PCB layouts.
This product is highly suited for use in electronic components assembly and industrial manufacturing where durable and precise PCB connections are mandatory. Browse more PCB Sockets and electronic connectors on EnvMart to find compatible components and accessories for your projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this socket is 2.54 mm, allowing for compact arrangements on PCBs.
The maximum operating temperature for the SMH-108-02-L-S is 125°C, making it suitable for a variety of applications.
This socket features 8 female contacts arranged in a single row.
The housing is made from Liquid Crystal Polymer, while the contacts are made of phosphor bronze and plated with gold for conductivity.
Yes, this socket is RoHS compliant, ensuring it meets environmental standards for hazardous substance limitations.
The SMH-108-02-L-S utilizes solder termination for secure attachment to PCB surfaces.
The orientation of this socket is straight, facilitating straightforward integration into PCB designs.
The minimum operating temperature for the SMH-108-02-L-S is -55°C, allowing it to function in extreme conditions.
This model is designed for board-to-board connector systems, providing reliable connections between PCBs.
The weight of this socket is not specified in the provided information.
It is suitable for industrial, manufacturing, and electronic component assembly applications, including prototyping and production boards.
This socket is RoHS compliant, adhering to standards for limiting hazardous substances in electronic components.
