Samtec Pin Header 1 Contact 2.54 mm Pitch 1 Row Unshrouded Through Hole Board-to-Board Connector TSW-101-07-S-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-101-07-S-S |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 1 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Operating temp range | -55 °C to +125 °C with Gold -55 °C to +105 °C with Tin |
| Plating used | Au or Sn over 50 μ" (1.27 μm) Ni |
Key Features
- Constructed with glass filled polyester housing for durability.
- Male phosphor bronze contact plated with gold for corrosion resistance.
- Designed for board-to-board connector systems with one row configuration.
- Operates reliably from -55°C to 125°C for various industrial applications.
- Through hole mounting ensures secure PCB connection in assembly.
- Unshrouded pins facilitate easy soldering and electrical contact.
Product Description
Samtec TSW-101-07-S-S pin header is a precision electronic component designed for robust PCB connection with one contact aligned in a single row. It features a 2.54 mm pitch and an unshrouded straight male pin configuration, allowing straightforward through hole mounting and solder termination.
The housing is made from black glass filled polyester, ensuring mechanical strength and thermal stability. The pins are crafted from phosphor bronze, plated with gold over nickel to provide excellent conductivity and corrosion resistance, supporting high reliability in demanding environments.
This pin header operates over a temperature range of -55°C to 125°C, making it suitable for industrial, manufacturing, electronics assembly, and other critical applications requiring durability and temperature tolerance. It supports a voltage rating of up to 550 V, compliant with typical PCB connector system standards.
The single row arrangement and unshrouded contacts facilitate ease of soldering and inspection during assembly, ideal for board-to-board connections. Its through hole mount type provides secure mechanical retention and electrical stability.
Constructed with durable glass filled polyester housing. Gold plated phosphor bronze male contact ensures reliable conductivity. Through hole mounting type suited for robust PCB assembly. Capable of operating in extreme temperature environments from -55°C to 125°C.
Voltage rating up to 550 V compatible with standard PCB connector systems. Unshrouded design for easy soldering and inspection. Single row, 2.54 mm pitch suitable for versatile electronic applications.
Ideal for electronics manufacturing, industrial equipment assembly, laboratory electronics, and commercial electronic systems. The Samtec TSW series is widely used across electronic component assemblies for reliable board-to-board connections.
Explore a wide range of professional PCB headers and connectors on EnvMart for industrial and commercial electronics projects.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header is 2.54 mm.
It can operate at a maximum temperature of 125°C.
This pin header utilizes a through hole mounting type, ensuring secure PCB connection during assembly.
The housing is made of glass filled polyester, while the contacts are phosphor bronze plated with gold for corrosion resistance.
The voltage rating for this model is up to 550 V, making it suitable for standard PCB connector systems.
This pin header features a single contact in a one-row configuration.
It operates reliably within a temperature range of -55°C to 125°C.
The termination type for this model is solder, facilitating easy assembly.
This model features an unshrouded design, which allows for easy soldering and inspection.
The contact gender of this pin header is male.
It is suitable for industrial, manufacturing, electronics assembly, and other critical applications requiring durability and temperature tolerance.
The country of origin for this pin header is India.
