Samtec Straight Through Hole Pin Header 17 Contacts 2.54 mm Pitch 1 Row Unshrouded TSW-117-14-L-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-117-14-L-S |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 17 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Features a single row configuration for easy PCB mounting.
- Constructed with glass filled polyester housing for durability.
- Gold plated phosphor bronze contacts ensure excellent conductivity.
- Rated for 550V operation and temperatures from -55°C to 125°C.
- Unshrouded design allows easy access to contacts.
- Through-hole solder termination for secure mechanical and electrical connection.
- Suitable for board-to-board connector systems requiring precise alignment.
- Industry tested for extended life and high mating cycles.
Product Description
The Samtec TSW-117-14-L-S is a straight through hole pin header designed for industrial and electronic applications requiring reliable board-to-board connections. It provides 17 gold-plated phosphor bronze contacts arranged in a single row with a 2.54 mm pitch, ensuring precise alignment and excellent conductivity.
The housing is made of robust glass filled polyester material, capable of withstanding operating temperatures ranging from -55°C to 125°C. It supports voltages up to 550 volts, making it suitable for a wide range of PCB connector applications.
This unshrouded pin header features a through-hole solder termination type, which guarantees a secure mechanical and electrical connection for PCB assemblies. Its design allows for easy access to contacts and adaptability in various electronic equipment designs.
The TSW series from Samtec is known for its extended life, passing rigorous mixed flowing gas tests and achieving high mating cycle ratings, making this product a dependable choice for manufacturing, industrial, communication, and laboratory electronics where durability is critical.
Features a single row configuration for easy PCB mounting. Constructed with glass filled polyester housing for durability. Gold plated phosphor bronze contacts ensure excellent conductivity. Rated for 550V operation and temperatures from -55°C to 125°C.
Unshrouded design allows easy access to contacts. Through-hole solder termination for secure mechanical and electrical connection. Suitable for board-to-board connector systems requiring precise alignment. Industry tested for extended life and high mating cycles.
This pin header is ideal for use in manufacturing electronic assemblies, circuit board connectors, communication devices, industrial automation equipment, and laboratory instrumentation. Compatible with various PCB designs requiring standardized spacing and reliable contact systems.
Explore additional Samtec connectors and PCB header products on EnvMart for more options tailored to your industrial and electronic component needs.
Explore more products in our PCB Pin Header category.
