Samtec DW Series Straight Through Hole Pin Header, 1 Contact, 2.54 mm Pitch, 1 Row, Unshrouded DW-01-07-T-S-200

Free Delivery in India | Lowest Global Shipping Charges

Samtec DW Series Straight Through Hole Pin Header, 1 Contact, 2.54 mm Pitch, 1 Row, Unshrouded DW-01-07-T-S-200

Name: Samtec DW Series Straight Through Hole Pin Header, 1 Contact, 2.54 mm Pitch, 1 Row, Unshrouded DW-01-07-T-S-200
Brand: Samtec
SKU: 162286



Category PCB Headers Brand Samtec Condition New

Specifications

Country of Origin	India
Brand	Samtec
Orientation	Straight
Model	DW-01-07-T-S-200
Mount Type	Through Hole
Housing Material	Black Glass Filled Polyester
Contact Material	Phosphor Bronze
Series	DW
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold over Tin
Number of Contacts	1
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board
Tail Pin Length	2.79mm

Key Features

Through-hole mounting ensures secure installation.
2.54 mm pitch with a single row configuration.
Unshrouded design provides versatile connectivity options.
Contacts plated with gold over tin for reliable conductivity.
Contact material made of phosphor bronze for durability.
Black glass filled polyester housing enhances strength and insulation.
Operates efficiently within -55°C to 105°C temperature range.
Male contact gender with 2.79 mm tail pin length for solder termination.

Product Description

Samtec DW-01-07-T-S-200 is a high-quality straight through hole pin header with 1 contact and a 2.54 mm pitch, designed for reliable board-to-board PCB connections.

This unshrouded pin header features a single row configuration, ensuring straightforward integration into various electronic assemblies. The black glass filled polyester housing provides robust insulation and mechanical stability, complementing the gold over tin plated phosphor bronze contacts for optimal electrical performance.

Ideal for applications in industrial electronics, automation systems, and mechanical projects, this pin header supports solder termination through its 2.79 mm tail pins, offering secure and durable mounting.

The component operates efficiently across a wide temperature range (-55°C to 105°C), making it suitable for demanding environments. Through-hole mounting offers a secure and easy installation solution. The 2.54 mm pitch and single-row layout optimize space and connectivity.

Unshrouded design increases accessibility for various connection scenarios. Gold over tin plating ensures reliable, corrosion-resistant contacts. Phosphor bronze contacts provide mechanical strength and conductivity. Robust black glass filled polyester housing improves durability and insulation.

Wide operating temperature range enables use in harsh industrial settings. Solder termination tail pins guarantee strong PCB mounting.

This pin header is widely used in PCB assemblies for electronics manufacturing and repair, automation control systems requiring stable and accurate signal transmission, and precise mechanical projects demanding high-reliability connectors.

Explore more about Samtec connectors and PCB components in EnvMart's extensive Electronics & Electricals category.

Explore more products in our PCB Headers category.
