Crydom SSR Series Solid State Relay, 25 A Load, Through Hole Mount, 280 V Load, 32V Control 84140810

Crydom 84140810 SSR Series Solid State Relay is a high-performance solid state relay designed for industrial and automation applications requiring reliable zero voltage switching. It supports a maximum load current of 25 A and a maximum load voltage of 280 V, with a dual AC output configuration allowing independent output channels for versatile control.

The relay is through hole mounted with solder pin terminals ensuring secure and durable PCB connections. It uses back-to-back SCR output suitable for heavy industrial loads, featuring a direct bond copper substrate for efficient heat dissipation and long service life.

This device offers robust electrical isolation rated at 4000 Vac optically coupled between input and output, enhancing safety during operation. Internal transient voltage suppression (TVS) components eliminate the need for external transient protection, simplifying system design.

Operating temperature range from -40°C to 80°C enables deployment in harsh environments. The relay’s low off-state leakage current of 0.1 mA minimizes power losses and unwanted conduction. Its capacitance of 8 pF helps reduce false triggering and signal interference, crucial for precision applications.

Typical industrial uses include automation control systems, HVAC equipment, machinery operation, water treatment process control, and other commercial or manufacturing environments requiring reliable switching solutions with low maintenance.

The compact dimensions of 57.2 mm length, 30.6 mm width, and 22.5 mm height allow for space-efficient installations while maintaining robust performance. It complies with RoHS standards and is UL/cUL recognized, assuring quality and regulatory adherence.

Package contains one Crydom SSR Series Solid State Relay unit with specifications as detailed. This product is suitable for engineers, technicians, and system integrators looking for efficient and durable solid state relay solutions.

This relay uses zero voltage switching to minimize electrical noise. Suitable for high industrial loads with a back-to-back SCR output. Features dual AC output relays with independent output operation. Equipped with 4000 Vac optical isolation for safe and stable performance.

Internal TVS provides protection against transients with no external components needed. Capacitance rated at 8 pF reduces interference and leakage currents. Operating temperature ranges from -40°C to 80°C for diverse environmental conditions.

Compact dimensions: length 57.2mm, width 30.6mm, height 22.5mm. Off state leakage current is minimal at 0.1 mA during standby. Terminal type is solder pin for secure PCB mounting.
