KEMET Film Capacitor 270 nF 1.6 kV DC 650 V AC Through Hole ±5% Tolerance R76TR327050H3J

KEMET R76TR327050H3J Film Capacitor is designed for high-reliability industrial and electronic applications requiring stable high frequency performance. This component features 270 nF capacitance with a ±5% tolerance, capable of handling a rated DC voltage of 1.6 kV and AC voltage of 650 V. It uses a through hole mount type suitable for durable PCB connections.

The capacitor construction employs polypropylene film together with double metallized polyester film electrodes and radial leads made from tinned wire. These leads are electrically welded to the metal layers ensuring robust electrical connection. It is encapsulated in a self-extinguishing, solvent-resistant plastic housing with thermosetting resin, enhancing durability in demanding operational conditions.

This device supports an operating temperature range of -55°C to 125°C, which makes it suitable for environments requiring thermal stability. The lead pitch measures 27.5 mm with lead length of 25 mm and a lead diameter of 0.8 mm facilitating easy soldering.

It fulfills automotive quality requirements with AEC-Q200 certification and complies with major international standards including RoHS and IEC 60286-2. The equivalent series resistance (ESR) is 15 mΩ, and the dissipation factor is low at 0.06%, ensuring efficient energy usage.

Polypropylene and metallized polyester film electrodes with robust radial tinned wire leads. Self-extinguishing plastic encapsulation withstands harsh environmental and mechanical stresses. Wide voltage rating with 1.6 kV DC and 650 V AC tolerances for demanding power circuits.

Ideal for resonant circuits, snubber applications, and high frequency switching including SCR and MOSFET. Lead-free solder terminations enhance environmental safety. Quality assurance via AEC-Q200 certification for automotive applications.

Packaged in trays for optimized storage and handling during mass production.

This film capacitor is commonly used in industrial manufacturing, automotive electronics, power electronics, telecommunications, and in high-frequency signal processing devices. Its combination of high voltage tolerance, accuracy, and temperature resilience makes it well suited for commercial and industrial electronics requiring reliable long-term performance.

For further technical integration and compatibility, KEMET provides detailed data sheets and support documents. Explore the full Film Capacitor range available at EnvMart for related components designed to meet stringent industrial standards.
