STMicroelectronics 16-Pin SOIC 5-Channel 1000 kHz 20V Current Mode PWM Controller L5991D
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.65mm |
| Length | 10mm |
| Model | L5991D |
| Width | 4mm |
| Mount Type | Surface |
| Maximum Duty Cycle | 85% |
| Output Current | 1.5A |
| Maximum Operating Temperature | 150°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 5 |
| Output Voltage | 5.07V |
| Maximum Switching Frequency | 1000kHz |
| Pin Count | 16 |
| Maximum Supply Voltage | 20V |
| Minimum Supply Voltage | 12V |
| Supply Current | 10mA |
| PWM Controller Type | Current Mode |
Key Features
- Supports a maximum switching frequency of 1000 kHz for efficient power conversion.
- Operates with a supply current of 10 mA ensuring low power consumption.
- Provides an output voltage of 5.07 V at a current of 1.5 A across 5 output channels.
- Surface mount type (SOIC) package with 16 pins for compact PCB integration.
- Operates in a temperature range of -40°C to 150°C for industrial robustness.
- Features a maximum duty cycle capability of 85% for versatile control.
- Measures 10 mm in length, 4 mm in width and 1.65 mm in height, suitable for space-constrained applications.
- Employs current mode PWM controller type for precise and stable switching.
Product Description
STMicroelectronics L5991D is a 5-channel pulse-width modulation (PWM) controller housed in a 16-pin SOIC surface mount package. This PWM controller utilizes current mode control technology and is capable of switching frequencies up to 1000 kHz, making it suitable for a variety of power management applications including isolated and non-isolated AC-DC and DC-DC converter topologies such as fly-back, forward, and quasi-resonant converters.
The device provides 5 output channels with an output current rating of 1.5 A and an output voltage of approximately 5.07 V, operating on supply voltages ranging from 12 V minimum to 20 V maximum. It offers a maximum duty cycle of 85%, allowing efficient power delivery with minimal losses.
Designed for rugged industrial environments, the L5991D operates reliably over a wide temperature range from -40°C to 150°C. Its compact dimensions of 10 mm length, 4 mm width, and 1.65 mm height facilitate integration into high-density power supply designs.
The PWM controller is robustly engineered with integrated protections to enhance reliability in demanding manufacturing, industrial automation, and power management systems. It supports various Switch Mode Power Supply (SMPS) configurations including symmetric and asymmetric topologies.
Maximum switching frequency: 1000 kHz for high efficiency power regulation. Low supply current of 10 mA reduces overall power consumption. 5 outputs ensure multi-channel PWM control capability. Surface mount SOIC package suitable for automated PCB assembly.
Wide operating temperature range for use in industrial applications. Current mode control provides improved transient response and noise immunity. Compact form factor aids in space-saving electronic designs.
This PWM controller is ideal for use in industrial machines, power supplies, manufacturing equipment, and other electronic systems needing reliable multi-channel PWM control with precise electrical characteristics.
Explore more semiconductor Power Management ICs and devices by STMicroelectronics on EnvMart for your advanced electronic component requirements.
