Wurth Elektronik 4.7 nF Multilayer Ceramic Capacitor, 50V DC, ±10 % Tolerance, Surface Mount, X7R Dielectric 885012205065

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 4.7 nF Multilayer Ceramic Capacitor, 50V DC, ±10 % Tolerance, Surface Mount, X7R Dielectric 885012205065

Name: Wurth Elektronik 4.7 nF Multilayer Ceramic Capacitor, 50V DC, ±10 % Tolerance, Surface Mount, X7R Dielectric 885012205065
Brand: Wurth Elektronik
SKU: 155411
Price: 0.01 USD
Availability: InStock



Category MLCCs - Multilayer Ceramic Capacitors Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Voltage	50V dc
Brand	Wurth Elektronik
Operating Temperature	- 55 °C to +125 °C
Height	0.5mm
Length	1mm
Width	0.5mm
Mount Type	Surface
Series	WCAP-CSGP
Termination	Cu/Ni/Sn
Termination Type	Solder
Maximum Operating Temperature	125°C
Tolerance	±10 %
Capacitance	4.7nF
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS
Package/Case	0402
Dielectric	X7R
Suppression Class	Class II
Recommended soldering	Reflow, for 0603 and 0805 wave soldering is also allowed
Ceramic characteristics	Class I - NP0 , Class II - X7R , X5R

Key Features

Constructed with high performance X7R dielectric providing excellent capacitance stability.
Suitable for operation between -55°C and +125°C temperature range.
Small 1 mm by 0.5 mm by 0.5 mm dimensions ideal for compact PCB designs.
Termination consists of Cu/Ni/Sn, compatible with reflow soldering and wave soldering processes.
Complies with RoHS standards for environmental safety.
Class II suppression capacitor with versatile ceramic characteristics including NP0, X7R, and X5R options.
Designed for surface mount applications, series WCAP-CSGP.
Manufactured in Taiwan, Province Of China, ensuring consistent quality.

Product Description

Wurth Elektronik 885012205065 multilayer ceramic capacitor is a high-quality surface mount device designed for electronic component applications needing stable capacitance and reliable operation from -55°C to +125°C.

This capacitor has a nominal capacitance of 4.7 nF, with a rated voltage of 50V DC and tolerance of ±10 %. It features a 0402 package size with compact dimensions of 1 mm length, 0.5 mm width, and 0.5 mm height, making it highly suitable for compact circuit board layouts.

The dielectric material is X7R, known for good temperature stability and performance in diverse industrial and commercial electronics applications. Its termination of Cu/Ni/Sn ensures excellent solderability using reflow methods, and wave soldering for certain package sizes is also supported.

This capacitor complies with RoHS environmental standards, supporting eco-friendly manufacturing and applications. Class II ceramic properties give it moderate electrical characteristics suited for general-purpose use.

Typical usage includes filtering, noise suppression, coupling, and decoupling in circuits for industrial, automotive, consumer electronics, and telecommunications equipment. The WCAP-CSGP series capacitors are engineered for durability and long-term stability even under fluctuating conditions.

High performance X7R ceramic capacitor for stable capacitance. Compact 0402 surface mount package compatible with standard soldering processes. Wide operating temperature of -55°C to +125°C for industrial applications. RoHS compliant materials guarantee environmental safety standards.

Termination plating of Cu/Ni/Sn ensures reliable electrical and mechanical connections. Class II ceramic class with versatile dielectric characteristics. Manufactured and quality-controlled in Taiwan, Province Of China.

This capacitive component is an essential element for engineers and designers requiring high-quality multilayer ceramic capacitors in electronics manufacturing and repair operations. Explore Wurth Elektronik's comprehensive range of MLCCs for advanced circuit solutions on EnvMart.
