Bourns 1280 Shielded Wirewound Surface Mount Inductor with Ferrite DR & RI Core 12 μH ±20% 5.6 A Idc Q:26 SRR1280
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 7.5mm |
| Length | 12.5mm |
| Model | SRR1280 |
| Depth | 12.5mm |
| Packaging | Tape & Reel |
| Series | SRR1280 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite DR & RI |
| Inductance | 12μH |
| Standards/Approvals | RoHS |
| Package/Case | 1280 |
| Maximum DC Current | 5.6A |
| Maximum DC Resistance | 28mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 15MHz |
| Minimum Quality Factor | 26 |
| Inductor Construction | Shielded |
Key Features
- Constructed with a ferrite DR & RI core for reliable performance.
- Inductance tolerance of ±20% ensures stable operation.
- Maximum DC current rating of 5.6 amps suitable for demanding circuits.
- Shielded inductor design minimizes electromagnetic interference.
- Compact 1280 package with dimensions 12.5 mm length, 7.5 mm height, and 12.5 mm depth.
- Maximum operating temperature up to 125°C for harsh environments.
- Low maximum DC resistance of 28 milliohms reduces power loss.
- Termination style is solder for easy PCB mounting.
Product Description
Bourns SRR1280 shielded wirewound surface mount inductor combines robust construction with high performance, featuring a ferrite DR & RI core and shielded design for electromagnetic interference reduction. It offers an inductance of 12 μH with a tolerance of ±20% and supports a maximum DC current of 5.6 A, making it ideal for demanding electronic circuits.
The inductor comes in a compact 1280 package measuring 12.5 mm in length, 7.5 mm in height, and 12.5 mm in depth, facilitating easy integration onto printed circuit boards using solder termination. It is rated for maximum operating temperatures up to 125°C, ensuring reliable operation under harsh thermal conditions.
This component exhibits a low maximum DC resistance of 28 milliohms, reducing power losses and improving circuit efficiency. The minimum quality factor of 26 and maximum self-resonant frequency of 15 MHz support efficient energy storage and signal integrity.
Bourns SRR1280 inductors are RoHS compliant and constructed to meet environmental and safety regulations. They are particularly suitable for use in the input/output stages of DC/DC converters, as well as power supplies for portable communication equipment, camcorders, and LCD televisions.
Constructed with ferrite DR & RI core material for effective magnetic performance. Compact 1280 package size suited for surface mount technology. Shielded construction reduces electromagnetic interference and noise. Maximum DC current rating of 5.6 amps supports high current applications.
Low DC resistance minimizes power losses in the circuit. RoHS compliant ensuring adherence to environmental standards. Suitable for automotive and consumer electronics applications. Operating temperature range from -40°C up to 125°C.
Ideal for use in power supplies and DC/DC converter circuits. Explore our range of Surface Mount Inductors for your electronics hardware projects and industrial applications on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 12 μH with an inductance tolerance of ±20%.
It supports a maximum DC current rating of 5.6 A, making it suitable for demanding circuits.
This unit has dimensions of 12.5 mm in length, 7.5 mm in height, and 12.5 mm in depth.
The maximum operating temperature is rated at 125°C, allowing it to function in harsh environments.
It is constructed with a ferrite DR & RI core, which contributes to its effective magnetic performance.
The shielded design minimizes electromagnetic interference, enhancing the inductor's performance in sensitive applications.
The termination style is solder, facilitating easy mounting on printed circuit boards.
The maximum DC resistance is 28 milliohms, which helps reduce power loss in circuits.
It has a minimum quality factor of 26, supporting efficient energy storage and signal integrity.
The maximum self-resonant frequency is 15 MHz, which is important for maintaining signal integrity.
Yes, this model is RoHS compliant, ensuring it meets environmental and safety regulations.
It is particularly suitable for use in the input/output stages of DC/DC converters and power supplies for portable communication equipment, camcorders, and LCD televisions.
