SMC Pneumatic Guided Cylinder, 25mm Bore, 50mm Stroke, Double Acting, CQM Series, Through Hole Mount, Aluminium CDQMB25-50

The SMC CDQMB25-50 is a high-performance pneumatic guided cylinder engineered for precision linear motion and stability in complex automation systems. Utilizing a 25mm bore and 50mm stroke, this double acting cylinder is designed for situations requiring accurate, non-rotating guidance, such as material handling, packaging, and other industrial assembly operations.

Constructed with a robust aluminium alloy body and utilizing a slide bearing guide system, the CDQMB25-50 provides exceptional lateral load resistance and operational longevity. The rubber cushioning on both ends ensures dampened end-of-stroke impact for quieter and safer operation, while the cylinder supports a maximum piston speed of 500mm/s and a maximum operating pressure of 1 MPa, delivering excellent versatility for high-speed or heavy-load applications.

The cylinder's compact form factor, with dimensions of 95.5mm (length), 40mm (width), and 40mm (height), allows for seamless installation where space is limited, and its 288g weight eases integration into modular pneumatic setups. The through hole mount type and single rod configuration make the unit suitable for systems where stable, guided movement is essential. The operating temperature range of -10°C to 70°C allows reliable function across a wide range of industrial environments.

The CDQMB25-50 belongs to SMC's renowned CQM series, which is compatible with CQS and CQ2 mounting interfaces for replacement and retrofit projects. It is widely used in packaging machinery, pick-and-place systems, automotive production lines, and laboratory automation equipment where high precision and repeatability are critical. The cylinder supports direct load handling, lateral force resistance two to four times greater than conventional CQ series models, and includes a magnetic piston as standard.

Key industrial applications include manufacturing, process automation, assembly lines, and pneumatic handling where compactness, load resistance, and accuracy are required. Its slide bearing guide type and aluminium alloy construction combine to ensure long operational lifespan, even with frequent cycling and challenging loads.
