Samtec TSW Series Straight Through Hole Pin Header 46 Contacts 2.54mm Pitch 2 Row Unshrouded TSW-123-07-F-D

Samtec TSW-123-07-F-D is a straight through-hole pin header designed for high-quality electronic interconnections. It features 46 male contacts arranged in 2 rows with a 2.54 mm pitch. The connector uses phosphor bronze contacts plated with gold for excellent conductivity and corrosion resistance. Its housing is made of durable Polybutylene Terephthalate ensuring mechanical stability and insulation.

This pin header is intended for through-hole mounting on printed circuit boards, providing reliable board-to-board connectivity in industrial and commercial electronic devices. It operates efficiently within a temperature range of -55°C up to 125°C, making it suitable for demanding environments.

The electrical ratings include a current carrying capacity of 4.3A and voltage rating of 550V, supporting a wide range of electronic applications. The tail pin length of 2.54 mm and mating pin length of 5.84 mm contribute to secure solder joints and mating reliability.

The unshrouded design facilitates easy accessibility and flexible mating orientations, while the vertical orientation suits various assembly needs. This product does not carry specific industry approvals but offers many plating and ruggedizing options for cost and performance optimization.

Features 46 male phosphor bronze gold-plated contacts ensuring excellent conductivity. Constructed with Polybutylene Terephthalate housing material for durability. Designed for through-hole mounting offering secure board-to-board connections.

Supports operating temperatures from -55°C to 125°C suitable for harsh environments. Rated for 550V voltage and 4.3A current capacity to handle robust electrical loads. Standard 2.54 mm pitch and row pitch ensure compatibility with common PCB layouts.

Tail pin length of 2.54 mm and mating pin length of 5.84 mm provide reliable solder termination. Unshrouded configuration allows flexible mating options and easy access.

This Samtec TSW Series pin header is widely used in electronics manufacturing, industrial control systems, communications equipment, and other PCB assembly applications where reliable electrical connections are critical. It supports design innovation with many options for plating and ruggedizing.
