Samtec TSW Series Straight Through Hole Pin Header, 8 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-104-14-F-D

Free Delivery in India | Lowest Global Shipping Charges

Samtec TSW Series Straight Through Hole Pin Header, 8 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-104-14-F-D

Name: Samtec TSW Series Straight Through Hole Pin Header, 8 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-104-14-F-D
Brand: Samtec
SKU: 154553
Price: 0.62 USD
Availability: InStock



Category PCB Pin Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	550V
Brand	Samtec
Orientation	Straight
Current	4.3A
Model	TSW-104-14-F-D
Mount Type	Through Hole
Special Features	Many options for optimizing cost and performance with platings and ruggedizing features
Housing Material	Polybutylene Terephthalate
Contact Material	Phosphor Bronze
Series	TSW
Termination	Through-hole
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	8
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board
Tail Pin Length	2.79mm
Mating Pin Length	8.13mm
Contact System	.025" (0.635 mm) square post

Key Features

Constructed with phosphor bronze contacts plated in gold for superior conductivity.
Housing made from durable polybutylene terephthalate ensuring mechanical strength.
Operates reliably between -55°C and 125°C temperature range.
Rated for 4.3 amperes current and 550 volts operating voltage.
Unshrouded straight orientation design suitable for various industrial electronic applications.
Includes tail pin length of 2.79 mm and mating pin length of 8.13 mm for secure connections.
Optimized for ruggedizing and cost-performance balance with multiple plating options.
Meets standard through-hole termination and board-to-board connector system.

Product Description

Samtec TSW-104-14-F-D is a precision-engineered straight through-hole pin header designed for reliable electronic board-to-board connections. It features 8 male contacts arranged in 2 rows with a standard 2.54 mm (0.100 inch) pitch, making it widely compatible with industry PCB designs.

This pin header utilizes high-quality phosphor bronze contacts plated with gold, ensuring excellent electrical conductivity and corrosion resistance. The housing material is polybutylene terephthalate, providing robust insulation and mechanical durability for industrial environments.

It is specified to operate efficiently within a temperature range of -55°C to 125°C and supports a continuous current rating of 4.3A at an operating voltage of 550V, making it suitable for various electronic and industrial equipment.

The product is unshrouded with a straight orientation to accommodate diverse application needs. Tail pin length measures 2.79 mm while mating pin length extends to 8.13 mm, optimizing soldering and connector engagement quality.

With options for different plating and ruggedizing features, this pin header series is versatile for cost optimization and performance enhancement in embedded electronics, industrial control systems, and communication equipment.

Phosphor bronze contacts with gold plating for enhanced conductivity. Durable polybutylene terephthalate housing for electrical insulation. Operating temperature range from -55°C to 125°C. Current rating of 4.3 amperes and voltage rating of 550 volts.

Unshrouded, straight orientation design for flexible PCB mounting. Through-hole solder termination for secure electrical and mechanical connection. Two rows with 8 contacts, 2.54 mm pitch standard footprint. Suitable for industrial electronics and board-to-board connector applications.

This pin header is categorized under PCB Pin Headers, ideal for electronics manufacturing, industrial automation, telecommunications, and high-performance computing hardware assembly. Explore similar PCB connector solutions in the Electronics Components category to complement your designs.
