Samtec Pin Header 10 Contacts 2.54 mm Pitch 1 Row Straight Through Hole Male Unshrouded TSW-110-07-F-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.3A |
| Model | TSW-110-07-F-S |
| Mount Type | Through Hole |
| Special Features | Many options for optimizing cost and performance with platings and ruggedizing features |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.54mm |
| Mating Pin Length | 5.84mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Features a straight orientation for board-to-board connection.
- Contacts are made of phosphor bronze with gold plating for reliable conductivity.
- Housing is crafted from durable polybutylene terephthalate material.
- Rated for 4.3 A current and 550 V voltage operation.
- Tail pins measure 2.54 mm and mating pins 5.84 mm in length.
- Operating temperature range from -55°C to 125°C supports harsh environments.
- Termination type is solder through-hole suitable for PCB assembly.
- Offers multiple plating and ruggedizing options to optimize performance and cost.
Product Description
Samtec TSW-110-07-F-S pin header is a high-quality, straight through-hole male connector designed for electronic PCB applications. It features 10 contacts spaced at a 2.54 mm pitch arranged in a single row with an unshrouded housing, allowing versatile board-to-board interfacing.
The contact pins are manufactured from phosphor bronze, plated with gold to ensure excellent signal integrity, corrosion resistance, and long service life. The connector's housing is constructed from polybutylene terephthalate, providing mechanical robustness and thermal stability.
This pin header supports a maximum current of 4.3 A and can operate safely up to 550 V. Its operating temperature range from -55°C to 125°C makes it suitable for industrial, commercial, and harsh environment electronics systems.
The termination style is solder through-hole, facilitating secure mounting and electrical continuity on printed circuit boards. Tail pin length measures 2.54 mm and mating pin length 5.84 mm, conforming to standard pin header dimensions for compatibility with mating connectors.
With multiple plating and ruggedizing options, this connector series offers customization flexibility to optimize cost and performance specific to application needs. It is ideal for use in industrial electronics, instrumentation, networking equipment, consumer electronics, and other PCB-based assemblies requiring reliable and robust connections.
Features a straight orientation for board-to-board connection. Contacts are made of phosphor bronze with gold plating for reliable conductivity. Housing is crafted from durable polybutylene terephthalate material. Rated for 4.3 A current and 550 V voltage operation.
Tail pins measure 2.54 mm and mating pins 5.84 mm in length. Operating temperature range from -55°C to 125°C supports harsh environments. Termination type is solder through-hole suitable for PCB assembly. Offers multiple plating and ruggedizing options to optimize performance and cost.
Explore additional Samtec PCB headers and electronic components at EnvMart for advanced electronic assembly solutions.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This pin header is rated for a maximum current of 4.3 A.
It has a voltage rating of 550 V.
The contacts are spaced at a pitch of 2.54 mm.
The contacts are made of phosphor bronze with gold plating, while the housing is crafted from polybutylene terephthalate.
The operating temperature range is from -55°C to 125°C, making it suitable for harsh environments.
The termination type is solder through-hole, which is suitable for PCB assembly.
This model features 10 contacts arranged in a single row.
The tail pins measure 2.54 mm in length.
The mating pins are 5.84 mm in length.
This model is unshrouded, allowing for versatile board-to-board interfacing.
It is ideal for use in industrial electronics, instrumentation, networking equipment, and consumer electronics requiring reliable connections.
Yes, it offers multiple plating and ruggedizing options to optimize performance and cost for specific applications.
