Broadcom Encoder 8-Pin SMD, 15 mA Typical Supply Current, Surface Mount AEDR-8502-102

Free Delivery in India | Lowest Global Shipping Charges

Broadcom Encoder 8-Pin SMD, 15 mA Typical Supply Current, Surface Mount AEDR-8502-102

Name: Broadcom Encoder 8-Pin SMD, 15 mA Typical Supply Current, Surface Mount AEDR-8502-102
Brand: Broadcom
SKU: 151641
Price: 24.41 USD
Availability: InStock



Category Encoder & Decoder ICs Brand Broadcom Condition New

Specifications

Country of Origin	India
Brand	Broadcom
Height	950μm
Length	3.95mm
Model	AEDR-8502-102
Mount Type	Surface
Number of inputs	3
Series	AEDR
Maximum Operating Temperature	85°C
Package Type	SMD
Minimum Operating Temperature	-20°C
Pin Count	8
Maximum Supply Voltage	5.5V
Logic Family	AEDR-850x
Logic Function	Encoder
Minimum Supply Voltage	4.5V
Typical Supply Current	15mA
Encoding resolution	294 to 304 (lines/inch)

Key Features

Provides two-channel quadrature digital outputs and a third index output for direction sensing.
TTL compatible outputs enable easy interfacing with various signal processing circuits.
Compact surface mount leadless package with dimensions 3.95 mm by 3.4 mm by 0.9562 mm.
Operates on a single 5 V supply voltage with minimum 4.5 V and maximum 5.5 V input.
Suitable for operating temperatures from -20°C to 85°C.
Encoding resolution ranges from 294 to 304 lines per inch for precise measurements.
Built-in interpolator selectable by external pins for 1x, 2x, and 4x factors.
Ideal for integration into industrial, laboratory, construction, and manufacturing applications.

Product Description

Broadcom AEDR-8502-102 is a high-performance encoder featuring an 8-pin surface mount leadless package designed for compact installations. It delivers a typical supply current of 15 mA and supports a logic family from the AEDR-850x series.

The product provides two-channel quadrature digital outputs along with a third index digital output, enabling robust direction sensing and positioning applications. The TTL compatible output signals facilitate seamless integration with most signal processing devices.

Physically compact with a length of 3.95 mm and height of approximately 950 μm, this encoder operates efficiently within a voltage range of 4.5 V to 5.5 V and within a temperature window spanning from -20°C to 85°C, making it reliable under varying environmental conditions.

The encoding resolution varies between 294 to 304 lines per inch, suitable for applications requiring precise angular measurement. A built-in interpolator allows selectable multiplication factors of 1x, 2x, and 4x through external pin configuration, enhancing design flexibility.

Due to its surface mount technology and small size, the AEDR-8502-102 is widely applicable in industrial automation, laboratory instrumentation, construction machinery, HVAC systems, manufacturing processes, and precision measurement systems.

Provides two-channel quadrature outputs and a third index output for comprehensive direction sensing. TTL compatible outputs for easy interfacing with signal processing systems. Compact surface mount package measuring 3.95 mm by 3.4 mm by 0.9562 mm.

Operates at 15 mA typical current with stable 5 V single supply operation. Wide operating temperature range from -20°C to 85°C. Encoding resolution between 294 and 304 lines per inch. Selectable interpolator factors of 1x, 2x, and 4x via external pinouts.

Designed for high integration flexibility and compact system design.

This encoder is ideal for various industrial sectors including manufacturing automation, laboratory equipment, construction equipment controls, and HVAC systems. The compact SMD form factor supports modern compact electronic assemblies.

Explore the range of Broadcom semiconductor devices and encoders at EnvMart for precise and reliable sensor and logic IC solutions.
