STMicroelectronics 4-Element Uni-Directional TVS Diode, 300 W, 6-Pin SOT-23 ESDA25SC6
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.3mm |
| Length | 3.05mm |
| Model | ESDA25SC6 |
| Width | 1.75mm |
| Mount Type | Surface |
| Series | ESDAxxSCx |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 6 |
| Number of Elements per Chip | 4 |
| Diode Configuration | Common Anode |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 25V |
| Maximum Reverse Stand-off Voltage Vwm | 24V |
| Peak Pulse Power Dissipation Pppm | 300W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 9A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- This diode array offers Uni-Directional transient voltage suppression with a common anode diode configuration.
- Minimum breakdown voltage is rated at 25 V with a maximum reverse stand-off voltage of 24 V.
- It supports a maximum peak pulse current of 9 A and a test current of 1 mA.
- Designed to operate in temperatures ranging from -40 °C to 125 °C for robust industrial and electronic protection.
- The compact dimensions are 3.05 mm length by 1.75 mm width and 1.3 mm height, suitable for PCB mount applications.
- Offers Electrostatic Discharge (ESD) protection with 4 elements per chip.
- Features low maximum reverse leakage current of 1 μA to ensure device reliability.
Product Description
STMicroelectronics ESDA25SC6 4-Element Uni-Directional TVS Diode delivers transient voltage suppression with a peak pulse power dissipation of 300 W in a surface mount SOT-23 6-pin configuration. It is engineered for reliable ESD and surge protection in sensitive electronic circuits.
This diode array has a common anode configuration and provides Uni-Directional electrical protection with a minimum breakdown voltage of 25 V and maximum reverse stand-off voltage of 24 V. It can handle maximum peak pulse currents up to 9 A with test current rated at 1 mA.
Operating temperature range from -40 °C to 125 °C ensures suitability for demanding industrial, manufacturing, and electronic device protection applications. Its compact package of 3.05 mm length, 1.75 mm width, and 1.3 mm height enables efficient PCB footprint usage and automatic insertion into assembly processes.
The 4-element design provides integrated multi-line protection with minimal leakage current, ensuring high reliability for transient voltage suppression in communication and power lines.
Uni-Directional TVS diode with common anode configuration for ESD and surge protection. Surface mount SOT-23 package with 6 pins for compact PCB integration. 300 W peak pulse power dissipation suitable for robust transient suppression.
Operating temperature range of -40 °C to 125 °C for wide environmental tolerance. Low reverse leakage current of 1 μA to maintain circuit integrity. Four elements per chip to protect multiple lines simultaneously. Compact physical dimensions optimize board space.
This ESDA series component from STMicroelectronics is ideal for industrial electronics, communications equipment, and any system requiring robust transient voltage suppression and ESD protection. It supports improved product longevity and safeguards against voltage spikes effectively.
Explore the extensive range of TVS Diodes and semiconductor components at EnvMart for your design and manufacturing needs.
