STMicroelectronics 4-Element Uni-Directional TVS Diode 400 W, 6-Pin SOT-23 ESDA6V1SC6
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.3mm |
| Length | 3.05mm |
| Model | ESDA6V1SC6 |
| Width | 1.75mm |
| Mount Type | Surface |
| Series | ESDAxxSCx |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 6 |
| Number of Elements per Chip | 4 |
| Diode Configuration | Common Anode |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 6.1V |
| Maximum Reverse Stand-off Voltage Vwm | 5.2V |
| Peak Pulse Power Dissipation Pppm | 400W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 18A |
| Maximum Reverse Leakage Current | 20μA |
Key Features
- The diode configuration is common anode, providing effective transient voltage suppression.
- Designed for uni-directional operation with a minimum breakdown voltage of 6.1 V.
- Maximum reverse stand-off voltage of 5.2 V with low reverse leakage current of 20 μA.
- Capable of handling peak pulse currents up to 18 A and supports ESD protection.
- Compact dimensions with length 3.05 mm, width 1.75 mm, and height 1.3 mm.
- Operates reliably in temperatures ranging from -40°C up to 125°C.
- Test current is 1 mA ensuring precise performance characterization.
- Designed for surface mount applications in electronics and semiconductor circuits requiring overvoltage protection.
Product Description
STMicroelectronics ESDA6V1SC6 is a 4-element uni-directional transient voltage suppressor (TVS) diode array designed for ESD protection in sensitive electronic circuits. This TVS diode offers a peak pulse power dissipation of 400 W, delivered through a compact 6-pin SOT-23 surface mount package, making it ideal for space-constrained and automated PCB assembly environments.
The device features a common anode diode configuration with a minimum breakdown voltage of 6.1 V and a maximum reverse stand-off voltage of 5.2 V, guaranteeing effective suppression of transient voltage spikes and overvoltage conditions. With a peak pulse current capability of 18 A, it provides robust transient protection, especially against electrostatic discharges.
Its low reverse leakage current of 20 μA ensures minimal impact on circuit operation under normal conditions, and the device maintains functionality over a wide operating temperature range from -40°C to 125°C, suitable for various industrial and commercial electronic applications.
Compact in size, measuring 3.05 mm in length, 1.75 mm in width, and 1.3 mm in height, this TVS diode array is surface mountable and compatible with automated manufacturing processes. It is supplied on reels for efficient integrated circuit assembly workflows.
The diode configuration is common anode for optimized circuit protection. Uni-directional operation ensures targeted transient voltage suppression. Minimum breakdown voltage of 6.1 V for precise threshold protection. Maximum reverse stand-off voltage of 5.2 V for device safety.
Peak pulse power of 400 W supports high surge energy absorption. Temperature range from -40°C to 125°C supports diverse usage environments. Low maximum reverse leakage current of 20 μA for efficient power management. Test current of 1 mA defining operational characteristics.
Pin count of 6 in a compact SOT-23 package allows space-saving PCB designs. 4 elements per chip enable multi-point protection in one device.
This TVS diode array finds extensive use in industrial, consumer electronics, telecommunications, automotive, and other applications requiring reliable ESD and transient voltage protection. Its surface mount design improves assembly efficiency and reduces board space requirements. STMicroelectronics ESDA6V1SC6 is a robust choice for transient voltage protection in sensitive electronic modules, enhancing durability and signal integrity.
Explore additional specifications and related TVS Diode products in the semiconductor category for comprehensive protection solutions.
