onsemi MOSFET Gate Driver 2 Outputs 1.5 A 8-Pin SOIC Package 18V MC33151DG

Free Delivery in India | Lowest Global Shipping Charges

onsemi MOSFET Gate Driver 2 Outputs 1.5 A 8-Pin SOIC Package 18V MC33151DG

Name: onsemi MOSFET Gate Driver 2 Outputs 1.5 A 8-Pin SOIC Package 18V MC33151DG
Brand: onsemi
SKU: 149504



Category MOSFET Gate Driver Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.5mm
Length	5mm
Model	MC33151DG
Width	4mm
Mount Type	Surface
Series	MC33151
Output Current	1.5A
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Number of outputs	2
Rise Time	14ns
Pin Count	8
Minimum Supply Voltage	18V
Number of Drivers	2
Fall Time	16ns
Driver Type	MOSFET

Key Features

Delivers a maximum output current of 1.5 amperes for efficient MOSFET driving.
Featuring 2 output channels enabling dual driver configurations.
Packaged in an 8-pin Small Outline Integrated Circuit (SOIC) for surface mounting.
Operating voltage ranges from 18V minimum to a maximum supply voltage of 18V.
Rise and fall times of 14ns and 16ns respectively for rapid switching performance.
Functional across a temperature range of -40°C to 85°C for industrial reliability.
Suitable for driving MOSFET and IGBT devices in low side, high side, and half-bridge circuits.

Product Description

onsemi MC33151DG MOSFET Gate Driver is a high-performance power management integrated circuit designed to drive MOSFETs and IGBTs in various configurations including low side, high side, and half-bridge circuits. It features dual outputs with a peak current of 1.5 amperes per channel, supporting rapid switching thanks to its 14ns rise time and 16ns fall time within an 8-pin SOIC package.

This gate driver operates at a nominal voltage of 18 volts and supports a wide temperature range from -40°C to 85°C, ensuring reliable operation in demanding industrial and commercial electronics applications. The device surface mounting allows for compact PCB designs and efficient thermal management.

The MC33151DG is part of onsemi's MC33151 series, widely used in power management IC applications involving MOSFETs and IGBTs, providing enhanced switching control and protection. Its compact size and surface mount form factor make it ideal for automated production and insertions into machinery setups requiring efficient space utilization and performance.

Delivers a maximum output current of 1.5 amperes for efficient MOSFET driving. Features dual output channels supporting 2 drivers per IC. Packaged in a compact 8-pin SOIC suitable for surface mount technology. Operates between a voltage range of 18V ensuring compatibility with standard power circuits.

Provides fast rise and fall switching times of 14ns and 16ns respectively. Ranges in operating temperature from -40°C to a maximum of 85°C for robust industrial performance. Compact dimensions of 5mm length, 4mm width, and 1.5mm height increase design flexibility.

Ideal for use in industrial, manufacturing, electric vehicle, and power converter systems requiring reliable gate drive solutions.

This semiconductor device enables efficient power management in diverse electronic designs, making it essential in construction, automotive electrification, HVAC control systems, laboratory instrumentation, and commercial electronic equipment. Its performance characteristics ensure quick switching, minimal signal loss, and stable operation under varied environmental conditions.
