Samtec Shunt Straight Female Connector Red 2 Way 1 Row 2.54 mm Pitch SNT-100-RD-G
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Colour | Red |
| Color | Black |
| Orientation | Straight |
| Current | 4.3A |
| Length | 5.08mm |
| Model | SNT-100-RD-G |
| Depth | 6.1mm |
| Width | 2.54mm |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | SNT |
| Sub Type | Shunt |
| Number of Rows | 1 |
| Positions | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Female |
| Connector Gender | Female |
Key Features
- Constructed with phosphor bronze contacts for durability.
- Gold plating on contacts ensures excellent conductivity and corrosion resistance.
- Housing made of glass filled polyester offers strength and stability.
- Designed with a straight orientation and red color for easy identification.
- Compact size with 5.08 mm length and 2.54 mm width fits standard PCB layouts.
- Supports current up to 4.3 A for moderate power applications.
- Single row with 2 contacts optimized for jumper and shunt use.
- Connector gender is female, suitable for complementary male connectors.
Product Description
Samtec SNT-100-RD-G is a straight female shunt connector designed for PCB jumpers requiring 2-way connections. It features a 2.54 mm pitch and a compact footprint suitable for electronic component assemblies.
Manufactured with phosphor bronze contact material and gold plating, the connector ensures reliable electrical performance with resistance to corrosion and wear. The housing is made from glass filled polyester providing mechanical strength and insulation.
This red-colored shunt is designed with a straight orientation and a single row configuration containing two contacts. It supports a continuous current rating of 4.3 amperes, making it suitable for power distribution on PCB assemblies where moderate current levels are needed.
The connector's compact dimensions, including a length of 5.08 mm, width of 2.54 mm, and depth of 6.1 mm, are compatible with standard layouts and facilitate easy installation in electronic devices, industrial control systems, and communication equipment.
Ideal for use in electronics manufacturing, laboratory instrumentation, and general industrial equipment, this shunt connector provides a cost-effective solution for reliable signal and power connections.
Constructed with phosphor bronze for durability and electrical performance. Gold plated contacts ensure corrosion resistance and conductivity. Glass filled polyester housing offers mechanical strength and insulation. Red color coding allows easy identification on PCB boards.
2-way, single row with 2.54 mm pitch for standard PCB compatibility. Supports 4.3 A current, ideal for moderate power applications. Straight orientation with female gender for connector pairing. Compact size suitable for electronic, industrial, and laboratory use.
No industry certifications specified. Explore our extensive range of jumpers and shunts for diverse electronics and industrial needs at EnvMart.
Explore more products in our Jumpers & Shunts category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a continuous current rating of 4.3 amperes, making it suitable for moderate power applications.
The connector has a length of 5.08 mm, a width of 2.54 mm, and a depth of 6.1 mm, making it compact and compatible with standard PCB layouts.
It features phosphor bronze contacts for electrical performance, gold plating for corrosion resistance, and a housing made of glass filled polyester for mechanical strength.
The pitch of this connector is 2.54 mm, which is standard for many PCB applications.
This unit has 2 contacts arranged in a single row configuration, optimized for jumper and shunt use.
It is designed with a straight orientation, which facilitates easy installation on PCBs.
The housing of this connector is red, allowing for easy identification on PCB boards.
It is ideal for use in electronics manufacturing, laboratory instrumentation, and general industrial equipment.
This connector has a female gender, making it suitable for pairing with complementary male connectors.
Yes, the Samtec SNT-100-RD-G connector is manufactured in India.
This model belongs to the SNT series, which includes various shunt connectors.
It is a shunt connector designed specifically for PCB jumpers requiring 2-way connections.
