TRACOPOWER DC/DC Converter 5V DC Output, 400 mA, 18-36V DC Input, 2W Surface Mount TIM 2-2411SM

TRACOPOWER TIM 2-2411SM DC/DC Converter is a compact and efficient power supply module delivering 5V DC output at 400 mA from a wide input range of 18 to 36 V DC. It offers a maximum output power of 2 watts in a surface-mountable SMD-16 package measuring 24.3 mm length, 14.4 mm width, and 10.5 mm depth. The converter supports a wide operating temperature range from -40°C to +105°C, ensuring reliable operation in harsh industrial, medical, and electronic environments.

This DC/DC converter features high isolation voltage rated at 5 kV AC, suitable for reinforced I/O isolation conforming to IEC/ES 60601-1 3rd edition standards, making it ideal for medical applications requiring stringent safety norms. It delivers an efficiency of 79%, contributing to reduced power losses. The product is built under strict quality controls including ISO 13485 certification and IPC-A-610 Class 3 workmanship standards, ensuring superior product reliability and performance with an MTBF of 6,810,000 hours.

The TIM 2 series offers various input voltage options with a 2:1 input ratio and the TIM 2-2411SM specifically covers the input range of 18 to 36 V DC. This converter is optimized to meet electromagnetic compatibility requirements such as EN55022 class A. Its surface mount design allows easy integration into PCB assemblies used in industrial tools, electronic components, medical devices, and power management systems.

Compact surface mount design with dimensions 24.3 x 14.4 x 10.5 mm. High isolation voltage of 5 kV AC ensuring robust electrical separation. Wide operating temperature range from -40°C to +105°C for reliable performance.

Efficiency rating of 79% for energy-efficient operation. Designed for medical and reinforced I/O isolation applications with IEC/ES 60601-1 certification. Mean time between failures (MTBF) of 6,810,000 hours indicating high reliability.

Single output converter suitable for industrial and electronic component power supplies. Compliance with ISO 13485 quality standards and IPC-A-610 Class 3 workmanship. Input ratio of 1:12 with options for input voltages from 4.5 to 75 V DC.

TRACOPOWER DC/DC Converters are widely used in industrial power supplies, electronic circuits, medical equipment, and manufacturing machinery where clean isolated power is necessary. Browse EnvMart’s extensive Electronics & Electricals category for more power supply solutions and TRACOPOWER products.
