SMC Pneumatic Compact Cylinder 32mm Bore, 20 mm Stroke, Double Acting Aluminium Alloy Body CD55B32-20M

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Compact Cylinder 32mm Bore, 20 mm Stroke, Double Acting Aluminium Alloy Body CD55B32-20M



Category Pneumatic Cylinder Brand SMC Condition New

Specifications

Country of Origin	China
Brand	SMC
Body Material	Aluminium Alloy
Maximum Operating Pressure	1.5 Mpa
Height	46mm
Length	71mm
Model	CD55B32-20M
Gross Weight	317g
Width	46mm
Mount Type	Through Hole
Series	CD55
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-10°C
Stroke Length	20mm
Bore Diameter	32mm
Rod Type	Single
Action Type	Double Acting
Standards/Approvals	ISO 21287
Cushioning Type	Rubber
Piston Rod Gender	Male
Piston Rod Thread Standard	Metric
Piston Rod Thread Size	16 mm

Key Features

This compact cylinder complies with ISO 21287 standards.
Equipped with a rubber cushioning type for smooth operation.
Features a single male piston rod with 16 mm metric thread size.
Operates within a temperature range of -10°C to 70°C.
Max operating pressure is 1.5 Mpa with a maximum piston speed of 500 mm/s.
The cylinder body dimensions are 46 mm in width and height, with a total cylinder length of 71 mm.
Constructed from hard anodized aluminium alloy for durability and lightweight performance.
Includes magnetic sensing as standard for precise position detection.

Product Description

SMC CD55B32-20M Pneumatic Compact Cylinder belongs to the CD55 series, featuring a 32mm bore diameter and 20 mm stroke length. This double acting Pneumatic Cylinder is constructed with a robust aluminium alloy body, making it lightweight yet durable for various industrial applications.

The cylinder operates under ISO 21287 standards ensuring reliability and compatibility across pneumatic systems. It is designed for use in industrial automation, manufacturing, mechanical systems, and fluid power applications where precise motion control and compact size are critical.

The compact design includes rubber cushioning to minimize impact shock and noise, enhancing longevity and smooth functioning. The piston rod is single and male with a 16 mm metric thread, facilitating easy integration with other machine components.

The operating conditions range from a minimum of -10°C to a maximum of 70°C, with a maximum operating pressure of 1.5 MPa and piston speed reaching up to 500 mm/s. Dimensions of the cylinder body are 46 mm in both width and height, with a total length of 71 mm, suitable for space-constrained automation applications.

The hard anodized aluminium alloy body provides resistance to corrosion and wear, ideal for demanding environments. Magnetic sensing is standard, aiding in accurate position detection during operation.

This product is manufactured in China and is supplied new, continuing SMC’s standards for quality and performance. This compact cylinder complies with ISO 21287 standards. Equipped with a rubber cushioning type for smooth operation.

Features a single male piston rod with 16 mm metric thread size. Operates within a temperature range of -10°C to 70°C. Max operating pressure is 1.5 Mpa with a maximum piston speed of 500 mm/s. The cylinder body dimensions are 46 mm in width and height, with a total cylinder length of 71 mm.

Constructed from hard anodized aluminium alloy for durability and lightweight performance. Includes magnetic sensing as standard for precise position detection. Explore the extensive range of pneumatic components including this precision compact cylinder for efficient hydraulic and pneumatic tool solutions at EnvMart.
