Hirose Straight Surface Female 1 Port USB Type B USB Connector USB 2.0 ZX80-B-5P(30)
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 30V |
| Brand | Hirose |
| Orientation | Straight |
| Current | 1A |
| Model | ZX80-B-5P(30) |
| Mount Type | Surface |
| Contact Material | Copper Alloy |
| Series | ZX |
| Number Of Ports | 1 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -30°C |
| USB Type | USB Type B |
| Connector Gender | Female |
| USB Specification | USB 2.0 |
Key Features
- Compact and reliable design ideal for USB Type B connections.
- Supports a current rating of 1A and voltage up to 30V.
- Features a straight orientation with active latch mechanism ensuring secure connection.
- Operates reliably between -30°C to 85°C temperature range.
- Constructed with copper alloy contacts for durability and conductivity.
- Designed for surface mount with solder termination type for easy PCB integration.
- Supports high data transfer speed of 480 Mbps as specified in USB 2.0.
- Engineered for up to 10,000 mating cycles, reducing wear and extending connector lifespan.
Product Description
Hirose ZX80-B-5P(30) USB Connector is a straight, surface mount, female USB Type B connector compliant with USB 2.0 specifications, delivering high-speed data transfer up to 480 Mbps. This connector features an active latch mechanism that ensures a secure and reliable connection with a tactile click when mated. Its compact design makes it 60% smaller than standard mini USB connectors, contributing to space-saving PCB layouts.
The connector is designed to operate effectively within a temperature range from -30°C to 85°C, supporting a current of 1A and a maximum voltage of 30V. Copper alloy contacts provide excellent conductivity and durability. The solder termination type facilitates reliable PCB attachment in surface mount applications.
Durability is enhanced by the ability to withstand 10,000 mating cycles with a low unmating force of 8 Newtons, reducing wear and improving operational lifespan. The smooth mating and unmating action prolong the connector's reliability.
The ZX Series Micro-USB connectors are widely used in ultra-thin phones, data recorders, readers, cameras, camcorders, PDAs, and handheld GPS devices, offering design flexibility through different mounting styles and configurations.
Compact size reduces PCB footprint significantly. Active latch mechanism ensures connection stability. High durability with 10,000 mating cycles lifespan. Temperature range from -30°C to 85°C suitable for diverse environments.
High-speed 480 Mbps data transfer in compliance with USB 2.0. Solder termination supports secure surface mounting. Copper alloy contacts for reliable conductivity. Low unmating force reduces mechanical wear. Applicable for smartphones, cameras, and portable electronics.
This Hirose USB connector is well-suited for industrial, consumer electronics, telecommunications, and embedded system applications. Its robust specifications ensure dependable operation for high-frequency data communications and compact electronic devices.
Explore EnvMart's extensive collection of USB Connectors and electronic components for your project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this USB Type B connector is 30V.
It operates reliably within a temperature range of -30°C to 85°C.
This USB connector supports a current rating of 1A.
The ZX80-B-5P(30) uses a solder termination type for secure surface mounting.
It is engineered for up to 10,000 mating cycles, which helps reduce wear and extend its lifespan.
This model supports high-speed data transfer of up to 480 Mbps as specified in USB 2.0.
The contacts are constructed from copper alloy, providing excellent conductivity and durability.
This connector features a straight orientation.
It is suitable for various applications including industrial, consumer electronics, telecommunications, and embedded systems.
This connector is 60% smaller than standard mini USB connectors, aiding in space-saving PCB layouts.
The active latch mechanism ensures a secure and reliable connection with a tactile click when mated, enhancing connection stability.
The connector is manufactured in India.
