XP Power Isolated DC/DC Converter 1kV Output Voltage Through Hole Mount 10W F10
Specifications
| Country of Origin | India |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power F DC/DC Converter, 1kV/ 10 mA, 12V dc Inp |
| Brand | XP Power |
| Length | 71.1mm |
| Model | F10 |
| Depth | 21.6mm |
| Gross Weight | 142g |
| Width | 43.2mm |
| Mount Type | Through Hole |
| Series | F |
| Maximum Operating Temperature | 70°C |
| Package Type | ComPacT |
| Minimum Operating Temperature | -10°C |
| MTBF | 810000h |
| Number of outputs | 1 |
| Ripple and Noise | 0.1% |
| Maximum Output Power | 10W |
| Maximum Input Voltage | 12V dc |
| Minimum Input Voltage | 0V dc |
| Output Voltage 1 | 1kV |
| Output Current 1 | 10mA |
| Isolation Voltage | 3.5kV |
Key Features
- This converter supports a 12V DC maximum input voltage and 0V DC minimum input voltage.
- It features a single output with 10mA output current and low ripple and noise of 0.1%.
- The device uses a through hole mount type for robust mechanical stability.
- Its compact ComPacT package measures 71.1mm length, 43.2mm width, and 21.6mm depth.
- Designed for operating temperature range from -10°C to 70°C, suitable for harsh industrial environments.
- The isolation voltage rating is 3.5kV, ensuring safety and protection in electrical systems.
- The converter boasts an MTBF of 810000 hours, indicating high reliability.
- No external components or minimum load are required, offering ease of integration.
Product Description
XP Power F10 DC/DC Converter is an isolated power supply unit providing a high voltage DC output of 1kV at 10mA current, with a maximum output power of 10W. It operates from a 12V DC input range down to 0V, featuring a through hole mount design ideal for rugged and demanding electronic applications.
Its compact ComPacT packaging (71.1mm length, 43.2mm width, 21.6mm depth) allows easy integration on printed circuit boards. Designed for an operating temperature range of -10°C to 70°C, it ensures stable performance in harsh environments.
The F series from XP Power is known for low ripple and noise (0.1%), low EMI/RFI emissions, and short circuit protection. Isolation voltage is rated at 3.5kV, providing necessary electrical isolation for safety and system integrity. With a high MTBF of 810000 hours, it guarantees long term reliability and durability.
This DC/DC converter is suitable for a variety of industrial and commercial applications including capacitor charging, igniter systems, spark modules, piezoelectric devices, and field generation equipment. Its design eliminates the need for minimum loads or external components, simplifying the system design.
This converter supports a 12V DC maximum input voltage and 0V DC minimum input voltage. Features a single output providing 1kV voltage at 10mA current. Compact ComPacT package measuring 71.1mm x 43.2mm x 21.6mm. Designed to operate between -10°C and 70°C ambient temperatures.
Robust through hole mount type for secure attachment. Isolation voltage of 3.5kV for enhanced electrical safety. Low ripple and noise ensures signal integrity. Short circuit protection included for reliability. Applications include capacitor charging and igniter modules.
XP Power products are trusted for their quality and durability across electronic component sectors. Explore our range of DC/DC Converters to find solutions for your power supply needs on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output voltage of this converter is 1kV.
It supports a maximum input voltage of 12V DC and a minimum input voltage of 0V DC.
The output current rating is 10mA.
The dimensions of this model are 71.1mm in length, 43.2mm in width, and 21.6mm in depth.
It is designed to operate within an ambient temperature range of -10°C to 70°C.
The isolation voltage rating is 3.5kV, ensuring safety in electrical systems.
The converter features a low ripple and noise specification of 0.1%.
It uses a through hole mount type for robust mechanical stability.
The maximum output power is 10W.
The mean time between failures (MTBF) is rated at 810,000 hours, indicating high reliability.
No, it does not require external components or a minimum load, simplifying integration.
It is suitable for various applications including capacitor charging, igniter systems, and piezoelectric devices.
