TDK Film Capacitor Through Hole Mount 18 nF 500V AC 1 kV DC 2-Pin Compact B32642B0183J000
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 11mm |
| Length | 18mm |
| Model | B32642B0183J000 |
| Width | 6mm |
| Mount Type | Through Hole |
| Series | B32642B |
| Maximum Operating Temperature | 110°C |
| Capacitance | 18nF |
| Standards/Approvals | UL, RoHS |
| Pin Count | 2 |
| Rated AC Voltage | 500V ac |
| Rated DC Voltage | 1kV dc |
| Lead Pitch | 15mm |
| Lead Diameter | 0.8mm |
| Automotive Standard | AEC-Q200 Rev D |
Key Features
- Compact film capacitor with a 2-pin through hole mounting design.
- Capacitance of 18 nanofarads suitable for high frequency applications.
- Rated AC voltage of 500 volts and DC voltage of 1 kilovolt.
- Complies with automotive standard AEC-Q200 Rev D.
- Maximum operating temperature of 110 degrees Celsius for reliable performance.
- Lead pitch spacing is 15 millimeters with lead diameter of 0.8 mm.
- Certified with UL and RoHS approvals ensuring quality and safety.
Product Description
The TDK B32642B0183J000 Film Capacitor is designed for high frequency electronic applications requiring stable capacitance and high voltage tolerance. This through hole mount capacitor features 18 nF capacitance, a rated AC voltage of 500 volts and a rated DC voltage of 1 kilovolt, ensuring robust performance in demanding electronic circuits.
It complies with the stringent automotive standard AEC-Q200 Rev D, making it suitable for automotive and industrial use cases where reliability under thermal and mechanical stress is critical. The capacitor can operate at a maximum temperature of 110°C, enabling it to withstand elevated temperature environments common in power electronics and switching circuits.
This model offers a compact form factor with dimensions of 18 millimeters in length, 11 millimeters in height, and 6 millimeters in width. The 2-pin through hole design with a 15 mm lead pitch and 0.8 mm lead diameter facilitates easy insertion and soldering on printed circuit boards.
Applications of this film capacitor include high frequency circuits with high current stress such as switched-mode power supplies, electronic ballasts for resonant circuits, and LLC typology resonant circuits. Its robust construction using wound capacitor technology ensures high pulse strength and current withstand capabilities.
2-pin through hole mounting for secure board installation. Compact size suitable for space-constrained PCB layouts. Automotive standard compliance for high reliability. High operating temperature tolerance up to 110°C. UL and RoHS certifications guarantee safety and environmental compliance.
Designed for switched-mode power supplies and high frequency resonant circuits. High pulse strength and current withstand thanks to wound capacitor technology.
The TDK B32642B0183J000 is an industrial-grade film capacitor ideal for electronics manufacturing, automotive electronics, HVAC systems, and power electronics applications requiring stable capacitance, high voltage tolerance, and reliable performance under thermal stress.
Explore more TDK Film Capacitors and similar high-quality passive components in the Electronics Components category at EnvMart to meet your industrial and commercial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance of 18 nanofarads (nF).
It has a rated AC voltage of 500 volts and a rated DC voltage of 1 kilovolt (kV).
The maximum operating temperature is 110 degrees Celsius.
It measures 18 mm in length, 11 mm in height, and 6 mm in width.
The lead pitch spacing is 15 mm, and the lead diameter is 0.8 mm.
This capacitor features a through hole mounting design with 2 pins.
It complies with the automotive standard AEC-Q200 Rev D.
It is certified with UL and RoHS approvals, ensuring quality and safety.
It is suitable for high frequency circuits such as switched-mode power supplies and electronic ballasts for resonant circuits.
It utilizes wound capacitor technology, which ensures high pulse strength and current withstand capabilities.
The compact size makes it suitable for space-constrained PCB layouts, allowing for efficient use of board space.
The country of origin for this capacitor is India.
