XP Power Q Series Ultra Miniature Isolated DC/DC Converter 12V dc Input 300V dc Output 0.5W Q03-12
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power Q DC/DC Converter, 300V dc/ 1 |
| Brand | XP Power |
| Length | 12.7mm |
| Model | Q03-12 |
| Gross Weight | 4.3g |
| Width | 12.7mm |
| Mount Type | Through Hole |
| Series | Q |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -25°C |
| MTBF | 3000000h |
| Number of outputs | 1 |
| Ripple and Noise | 0.25% Pk-Pk |
| Maximum Output Power | 0.5W |
| Maximum Input Voltage | 12V dc |
| Minimum Input Voltage | 0V dc |
| Number of Pins | 6 |
| Output Voltage 1 | 300V dc |
| Output Current 1 | 1.667mA |
| Isolation Voltage | 500V dc |
Key Features
- Ultra miniature case size provides compact and lightweight design.
- Input voltage range from 0V to 12V dc supports versatile power sources.
- Isolated output voltage of 300V dc with 1.667mA output current ensures safe operation.
- Low ripple and noise with 0.25% peak-to-peak maintains signal integrity.
- High MTBF of 3,000,000 hours for long-term reliability.
- Through-hole mounting facilitates easy PCB integration.
- Operating temperature range from -25 °C to 70 °C suits varied environmental conditions.
- Isolation voltage rating of 500V dc provides robust electrical isolation.
Product Description
XP Power Q03-12 is an ultra miniature isolated DC to high voltage DC converter in the Q Series, engineered for applications requiring small size and high reliability. Featuring a 12V dc input and high-voltage 300V dc output, this converter delivers a maximum output power of 0.5W with an output current of 1.667mA.
The device supports a wide input voltage range from 0V up to 12V dc and utilizes a through-hole mount type for secure PCB installation. It operates reliably over an extended temperature range of -25 °C to 70 °C and offers an isolation voltage of 500V dc to ensure electrical safety and noise reduction in sensitive applications.
Designed with low ripple and noise at 0.25% peak-to-peak, the Q03-12 converter ensures excellent signal integrity suitable for precision electronics. The ultra-miniature enclosure measures just 12.7mm by 12.7mm, weighing approximately 4.3 grams, making it suitable for compact and lightweight system designs.
Key technical features include a mean time between failures (MTBF) of 3,000,000 hours indicating high reliability, one output channel, and a 6-pin configuration. The converter requires no external components and features short circuit protection to safeguard connected circuits.
Its applications span avalanche photodiodes, photomultiplier tubes, piezo devices, sustaining ion pumps, electrophoresis equipment, printers, igniters, capacitor charging circuits, and other industrial, laboratory, and medical instrumentation requiring isolated high-voltage DC power.
This product is made in the United States and complies with UL and RoHS standards, ensuring quality and environmental safety. Ultra miniature and reliable isolated DC/DC conversion. Wide input voltage range with low noise output.
High isolation voltage for electrical safety. Compact size and lightweight design. Long product lifecycle with high MTBF. Internal short circuit protection included. Through-hole mounting for secure PCB integration. Ideal for specialized industrial and scientific applications.
Explore more in the DC/DC Converter category on EnvMart for advanced power conversion solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for this model is from 0V to 12V dc.
It provides an isolated output voltage of 300V dc with an output current of 1.667mA.
The maximum output power of this unit is 0.5W.
The isolation voltage rating is 500V dc, ensuring robust electrical isolation.
The dimensions of the converter are 12.7mm by 12.7mm.
This model weighs approximately 4.3 grams.
It utilizes a through-hole mounting type for secure PCB installation.
The operating temperature range is from -25 °C to 70 °C.
It features low ripple and noise at 0.25% peak-to-peak, which helps maintain signal integrity.
This converter is suitable for applications such as avalanche photodiodes, photomultiplier tubes, and electrophoresis equipment.
The MTBF for this unit is 3,000,000 hours, indicating high reliability.
Yes, it includes internal short circuit protection to safeguard connected circuits.
