Power Integrations AC/DC Converter 7W, 1.35 A, 50 V DC, 7-Pin DIP TNY286PG
Specifications
| Country of Origin | India |
|---|---|
| Brand | Power Integrations |
| Height | 3.68mm |
| Length | 9.83mm |
| Model | TNY286PG |
| Width | 6.6mm |
| Output Power | 7W |
| Mount Type | Through Hole |
| Maximum Duty Cycle | 67% |
| Series | TinySwitch-4 |
| Topology | Flyback |
| Maximum Operating Temperature | 150°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Maximum Input Voltage | 265V ac |
| Maximum Output Current | 1.35A |
| Minimum Input Voltage | 85V ac |
| Pin Count | 7 |
| Supply Current | 470μA |
| Minimum Output Voltage | 50V dc |
| Self-biased | no bias winding or bias components |
Key Features
- Supports maximum input voltage of 265V AC and minimum input voltage of 85V AC.
- Features Flyback topology for efficient power conversion.
- Operates within a temperature range of -40°C to 150°C.
- Compact dimensions of 9.83mm length, 6.6mm width, and 3.68mm height.
- Includes self-biased design requiring no bias winding or components.
- Offers selectable current limit through BP/M capacitor value.
- Provides accurate hysteretic thermal shutdown with automatic recovery.
- Simple ON/OFF control system with no loop compensation needed.
Product Description
Power Integrations TNY286PG is an advanced AC/DC Converter designed for energy-efficient off-line power management applications. It combines a high-voltage power MOSFET with an ON/OFF flyback power supply controller in a single 7-pin DIP compact package, delivering 7W output power and supporting a maximum output current of 1.35 A at 50 V DC output voltage.
This device supports wide input voltage ranges from 85V AC minimum to 265V AC maximum, operating reliably in temperature conditions ranging from -40°C to 150°C. The Flyback topology optimizes energy conversion efficiency while maintaining fast transient response and low no-load power consumption.
The TNY286PG includes important features such as self-biasing, which eliminates the need for external bias windings or components. It also offers selectable current limits through capacitor settings and frequency jittering to reduce electromagnetic interference filter costs. Protection features include accurate hysteretic thermal shutdown with automatic recovery and auto-restart capabilities.
With its through-hole mount type and small form factor dimensions of 9.83mm in length, 6.6mm in width, and 3.68mm in height, this 7-pin DIP package is suitable for various power supply designs across industrial, electronic equipment, and semiconductor applications.
Supports 265V AC maximum input voltage for high-voltage applications. Power output rating of 7W for mid-range power conversions. Flyback design topology ensures efficiency and compact design. Built-in thermal and current protection mechanisms enhance reliability.
Compact DIP package allows ease of PCB mounting and heat sinking. Self-biased design minimizes component count and design complexity. Wide operating temperature range suits industrial environments. Ideal for use in off-line power conversion in electronics and telecom equipment.
Explore an extensive range of semiconductor and power management ICs at EnvMart for your industrial and electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TNY286PG delivers an output power of 7W.
It supports a maximum input voltage of 265V AC.
The minimum input voltage is 85V AC.
The maximum output current is 1.35 A.
The dimensions are 9.83mm in length, 6.6mm in width, and 3.68mm in height.
It operates within a temperature range of -40°C to 150°C.
This model utilizes Flyback topology for efficient power conversion.
It features a through-hole mount type.
No, it has a self-biased design that eliminates the need for external bias windings or components.
It includes accurate hysteretic thermal shutdown with automatic recovery.
The supply current is 470μA.
It is suitable for various power supply designs across industrial, electronic equipment, and semiconductor applications.
