Wurth Elektronik 381 Series Pluggable Terminal Block 6-Contact 2.5 mm Pitch 1 Row Screwless Vertical Wire 691381030006

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 381 Series Pluggable Terminal Block 6-Contact 2.5 mm Pitch 1 Row Screwless Vertical Wire 691381030006

Name: Wurth Elektronik 381 Series Pluggable Terminal Block 6-Contact 2.5 mm Pitch 1 Row Screwless Vertical Wire 691381030006
Brand: Wurth Elektronik
SKU: 140407



Category Pluggable Terminal Blocks Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	300V ac
Brand	Wurth Elektronik
Colour	Green
Orientation	Vertical
Current	12A
Length	15.6mm
Depth	18.9mm
Width	11.8mm
Housing Material	Polyamide
Series	381
Number of Rows	1
Pitch	2.5mm
Number of Contacts	6
Connector Gender	Male
Minimum Wire Size mm²	0.21mm²
Maximum Wire Size mm²	3.31mm²
Minimum Wire Size AWG	24AWG
Maximum Wire Size AWG	16AWG
Wire Connection Method	Screwless

Key Features

Features a single-row configuration for compact PCB layouts.
Constructed with durable polyamide housing in green and orange UL94-V0 PA 66 material.
Accepts wire sizes from 24 AWG to 16 AWG, supporting minimum 0.21 mm² to maximum 3.31 mm².
Utilizes a push-in spring wire termination for easy and reliable connections without screws.
Designed for panel mounting with flange options on specific part numbers.
Applicable in industrial, electronics, and power connector systems requiring secure terminal connections.
Manufactured in China ensuring consistent quality standards.

Product Description

Wurth Elektronik 691381030006 is a high-quality 381 Series pluggable terminal block designed for applications requiring a secure, compact, and reliable connection system. Featuring 6 contacts arranged in a single row with a precise 2.5 mm pitch, this terminal block supports wire gauge sizes from 24 AWG (0.21 mm²) up to 16 AWG (3.31 mm²), making it versatile for various wiring needs.

The polyamide housing is manufactured from green and orange UL94-V0 PA 66 material, providing excellent durability, electrical insulation, and flame retardancy. The push-in spring wire termination method ensures quick, tool-free connections while eliminating the need for screws, reducing installation time and maintenance requirements.

With a current rating of 12A and voltage rating of 300V AC, it is suitable for power and signal connection applications in electronics assemblies, industrial automation, and control panels. The vertical orientation and compact footprint of 15.6 mm (length) x 11.8 mm (width) x 18.9 mm (depth) allow for dense PCB layouts and efficient use of space.

Some variants of the 691381030006 model include flanges designed for panel mounting, enhancing mechanical stability and ease of integration into enclosures. This terminal block mates with the WR-TBL 382 series terminal block header connectors, completing a two-part terminal block system ideal for modular connections.

Being manufactured in China, it adheres to consistent quality and performance standards sought by engineers and procurement teams. Its screwless push-in termination makes it a user-friendly choice for professionals who require safe, reliable, and fast wiring solutions.

Secure screwless push-in spring wire termination method. Compatible with 24 AWG to 16 AWG wire sizes. Compact 2.5 mm pitch and single-row layout. Durable polyamide housing with UL94-V0 flame retardant rating. Designed for 12A current and 300V AC voltage.

Includes flange options for panel mounting. Ideal for industrial, electronics, HVAC, and manufacturing applications.
