Wurth Elektronik 381 Series Pluggable Terminal Block 3-Contact 2.5 mm Pitch 1 Row 300V AC 12A 691381030003

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 381 Series Pluggable Terminal Block 3-Contact 2.5 mm Pitch 1 Row 300V AC 12A 691381030003

Name: Wurth Elektronik 381 Series Pluggable Terminal Block 3-Contact 2.5 mm Pitch 1 Row 300V AC 12A 691381030003
Brand: Wurth Elektronik
SKU: 140405



Category Pluggable Terminal Blocks Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	300V ac
Brand	Wurth Elektronik
Colour	Green
Orientation	Vertical
Current	12A
Length	8.1mm
Depth	18.9mm
Width	11.8mm
Housing Material	Polyamide
Series	381
Number of Rows	1
Pitch	2.5mm
Number of Contacts	3
Connector Gender	Male
Minimum Wire Size mm²	0.21mm²
Maximum Wire Size mm²	3.31mm²
Minimum Wire Size AWG	24AWG
Maximum Wire Size AWG	16AWG
Wire Connection Method	Screwless

Key Features

Supports wire sizes from 24 AWG to 16 AWG for versatile applications.
Designed for a rated current of 12 amperes and voltage of 300 volts AC.
Constructed with durable polyamide housing ensuring reliable insulation.
Features a vertical orientation with a single row and a compact footprint.
Screwless push-in spring wire termination provides quick and secure connections.
Color coded in green to aid easy identification and installation.
Measures 8.1 mm length, 11.8 mm width, and 18.9 mm depth for compact PCB mounting.
Manufactured in China with consistent quality standards.

Product Description

Wurth Elektronik 691381030003 381 Series Pluggable Terminal Block is a high-quality electrical connector designed for efficient and secure wire terminations in electronic components and systems. With 3 contacts arranged in a single row and a pitch of 2.5 mm, this terminal block provides a compact footprint suitable for space-constrained PCB layouts.

This terminal block features a screwless push-in spring wire connection method, allowing quick and reliable termination without the need for screws. It accommodates wires ranging from 24 AWG (0.21 mm²) up to 16 AWG (3.31 mm²), supporting a maximum current of 12 amperes and a voltage rating of 300 volts AC. The durable polyamide housing material offers excellent insulation and mechanical protection, with a distinct green color for straightforward visual identification.

The compact dimensions of 8.1 mm length, 11.8 mm width, and 18.9 mm depth make this terminal block ideal for vertical mounting on PCBs where space efficiency is critical. It is part of the Wurth Elektronik 381 series and manufactured with precision in China, adhering to quality and reliability standards.

This terminal block is widely used in industrial control panels, electronic assemblies, automation equipment, and telecommunications due to its easy installation and robust contact reliability. For connector mating, it is compatible with the WR-TBL 382 series Terminal Block headers.

Supports wire sizes from 24 AWG to 16 AWG for versatile applications. Rated for 12 amperes current and 300 volts AC voltage operation. Polyamide housing material ensures durable electrical insulation. Compact 2.5 mm pitch and single row configuration saves PCB space.

Screwless push-in spring wire connection method for easy termination. Vertical orientation simplifies wiring layout. Green color coding aids quick component identification. Manufactured in China with stringent quality control.
