KEMET Metallised Polyester Film Capacitor Through Hole 220 nF 250 V DC 140 V AC ±5 % R82 Series R82IC3220DQ60J

KEMET R82IC3220DQ60J film capacitor is a metallised polyester film capacitor designed for through hole mounting. This component delivers a capacitance of 220 nF with a tolerance of ±5 %, rated for a DC voltage of 250 V and an AC voltage of 140 V.

The capacitor series R82 is engineered with radial leads of tinned wire electrically welded to the metal contact layers, encapsulated in a robust, self-extinguishing plastic case ensuring safety and solvent resistance. Its compact size includes dimensions of 7.2 mm length, 6 mm width, and 11 mm height, with a lead pitch of 5 mm and lead length of 18.5 mm.

It complies with IEC 60384-2 standards and adheres to RoHS directives, making it suitable for environmentally compliant electronic designs. The operating temperature range spans from -55°C to 105°C, supporting a wide climatic category of 55/105/56 for reliable use in demanding industrial and commercial environments.

This film capacitor is widely applied in industrial, laboratory, electronics manufacturing, telecommunications, and automotive sectors. It is ideally suited for blocking, coupling, decoupling, timing, and oscillator circuit applications. The AEC-Q100 automotive standard approval also supports usage in automotive electronics systems.

The capacitor is supplied in ammo pack packaging format, optimized for high-efficiency machine insertion in manufacturing lines, enhancing assembly productivity. Its self-healing property ensures longevity and consistent electrical performance.

This capacitor features metallised polyester film construction ensuring durability and reliability. It has a lead pitch of 5 mm suitable for standard through hole PCB layouts. Operating temperature range from -55°C to 105°C enables stable performance in diverse environments.

The product complies with IEC 60384-2 and RoHS regulations, assuring quality and environmental standards. Typical applications include blocking, coupling, decoupling, timing, and oscillator circuits. Component encapsulated in self-extinguishing, solvent-resistant plastic case with thermosetting resin material.

Available in ammo pack packaging facilitating automated insertion in production. Explore a wide range of capacitors and Film Capacitors at EnvMart for your electronics manufacturing and design requirements.
