STMicroelectronics TSX7192IDT Operational Amplifier Dual Channel 9 MHz Gain Bandwidth 16V SOIC 8-Pin
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.5mm |
| Length | 5mm |
| Model | TSX7192IDT |
| Width | 4mm |
| Mount Type | Surface |
| Series | TSX7192 |
| Output Current | 69mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | AEC Q100 and Q003 or equivalent |
| Pin Count | 8 |
| Automotive Standard | AEC-Q3, AEC-Q100 |
| Maximum Supply Voltage | 16V |
| Minimum Supply Voltage | 2.7V |
| GBP - Gain Bandwidth Product | 9MHz |
| Input Bias Current | 50 pA |
| Slew Rate | 2.5V/μs |
| ESD high tolerance | 4 kV (HBM) |
| Input Offset Current | 200 pA |
| Low current consumption | 850 μA max |
| Extended temperature range | -40 °C to +125°C |
Key Features
- Dual channel operational amplifier with 8-pin SOIC package.
- Gain bandwidth product of 9 MHz ensures high frequency performance.
- Operates over a wide voltage range from 2.7 V to 16 V.
- Low input offset voltage and low input bias current enhance precision.
- Robust design with automotive standard AEC-Q3 and AEC-Q100 certifications.
- Extended operating temperature range from -40 °C to +125 °C suitable for harsh environments.
- ESD protection rated at 4 kV (HBM) for increased reliability.
- Slew rate of 2.5 V/μs ensures fast transient response.
Product Description
STMicroelectronics TSX7192IDT is a precision dual operational amplifier designed for applications requiring low power consumption and high precision. This device features rail-to-rail input/output capability and a gain bandwidth product of 9 MHz, making it suitable for high frequency signal conditioning and amplification.
The amplifier operates from a single supply voltage range of 2.7 V up to 16 V, supporting a wide variety of electronic and automotive applications. It includes robust ESD protection rated at 4 kV (HBM) and complies with automotive standards AEC-Q3 and AEC-Q100, ensuring compatibility in demanding automotive and industrial environments.
Notable electrical characteristics include a low input offset voltage of 200 μV maximum, very low input bias current of 50 pA, and a slew rate of 2.5 V/μs, all contributing to high precision and fast response time. The device can operate reliably in extended temperature range conditions from -40 °C up to 125 °C.
Dual channel operational amplifier with precision and low noise. Wide supply voltage range from 2.7 V to 16 V for flexible system design. Automotive qualified with AEC-Q3 and AEC-Q100 standards. Low current consumption of 850 μA to reduce power usage.
Compact SOIC 8-pin packaging with small footprint. High ESD tolerance of 4 kV to protect against electrostatic discharge. Rail-to-rail input/output for maximal dynamic range. Suitable for use in automotive, industrial, and precision instrumentation applications.
This operational amplifier is ideal for electronic components, power management, amplifiers, automotive electronics, sensor interface, and other applications requiring reliable and precise amplification with low noise and power consumption. It supports surface mount assembly for efficient PCB design.
Explore more STMicroelectronics Operational Amplifiers and related products in the EnvMart Electronics & Electricals category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 9 MHz, ensuring high frequency performance for various applications.
It operates over a supply voltage range from 2.7 V to 16 V, making it suitable for a variety of electronic applications.
The maximum output current for this operational amplifier is 69 mA, allowing it to drive loads effectively.
This operational amplifier can operate in an extended temperature range from -40 °C to +125 °C, suitable for harsh environments.
It comes in an 8-pin SOIC package, which is designed for surface mount applications.
The input bias current is 50 pA, and the input offset current is 200 pA maximum, contributing to its precision performance.
The slew rate of the TSX7192IDT is 2.5 V/μs, ensuring fast transient response in signal processing applications.
It complies with automotive standards AEC-Q3 and AEC-Q100, ensuring reliability in automotive applications.
The TSX7192IDT has ESD protection rated at 4 kV (HBM), enhancing its reliability against electrostatic discharge.
The maximum low current consumption is 850 μA, which helps in reducing power usage in applications.
This operational amplifier features two channels, allowing for dual signal processing capabilities.
The dimensions of this operational amplifier are 1.5 mm in height, 5 mm in length, and 4 mm in width.
