Renesas Electronics Line Transceiver, CMOS Bus Transceiver, Differential Input, 3 State Output, Surface Mount ISL3170EIUZ

Free Delivery in India | Lowest Global Shipping Charges

Renesas Electronics Line Transceiver, CMOS Bus Transceiver, Differential Input, 3 State Output, Surface Mount ISL3170EIUZ

Name: Renesas Electronics Line Transceiver, CMOS Bus Transceiver, Differential Input, 3 State Output, Surface Mount ISL3170EIUZ
Brand: Renesas Electronics
SKU: 138199
Price: 2.27 USD
Availability: InStock



Category Line Interface ICs Brand Renesas Electronics Condition New

Specifications

Country of Origin	India
Brand	Renesas Electronics
Height	850μm
Length	3.05mm
Model	ISL3170EIUZ
Width	4.9mm
Mount Type	Surface
Output type	3 State
Series	ISL3170E
Input Type	Differential
Maximum Operating Temperature	85°C
Package Type	MSOP
Minimum Operating Temperature	-40°C
IC Type	Line Transceiver IC
Standards/Approvals	RS-485, IEC61000 ESD, RoHS, RS-422
Pin Count	10
Maximum Supply Voltage	3.6V
Logic Family	CMOS
Logic Function	Bus Transceiver
Minimum Supply Voltage	3V
Maximum High Level Output Current	4mA
Maximum Propagation Delay Time @ CL	1500ns
Supply Current	800μA

Key Features

Operates with a minimum supply voltage of 3V and maximum of 3.6V.
Maximum high and low level output current is 4mA each.
Maximum propagation delay time at CL is 1500ns.
Designed to operate within temperature range from -40°C to 85°C.
Compact dimensions include 3.05mm length, 4.9mm width, and 850μm height.
Supply current is 800μA ensuring low power consumption.
Complies with RS-485, IEC61000 ESD, RoHS, and RS-422 standards.
Suitable for reliable data transmission over long twisted pair wiring in half and full duplex RS-485 applications.

Product Description

Renesas Electronics ISL3170EIUZ line transceiver belongs to the CMOS logic family and functions as a bus transceiver designed for reliable data transmission over long twisted pair wiring in industrial, automation, and communication applications.

This line transceiver provides differential inputs and 3 state outputs enabling half duplex and full duplex RS-485 and RS-422 communication protocols. The device features a 10-pin MSOP surface mount package with compact physical dimensions of 3.05mm length, 4.9mm width, and 850μm height.

Operating voltage ranges from 3V minimum to 3.6V maximum, while the device draws 800μA supply current, ensuring energy-efficient performance. It supports a maximum high and low level output current of 4mA and has a propagation delay time of up to 1500ns at the specified load capacitance, suitable for various data rates.

The component is rated for operation in industrial temperature ranges from -40°C up to 85°C, making it robust for harsh environments. Certifications and standards compliance include RS-485, IEC61000 electrostatic discharge, RoHS environmental compliance, and RS-422 communication standard.

This transceiver is intended for integration into electronic systems requiring reliable half and full duplex serial data communication over twisted pair cables such as industrial controls, building automation, and communication equipment.

Operates in half and full duplex RS-485 and RS-422 applications. Compact 10-pin MSOP surface mount package. Low supply current of 800μA for power efficiency. Wide temperature range from -40°C to 85°C. High immunity to ESD per IEC61000 standards.

RoHS compliant for environmental safety. Supports maximum 4mA output current levels for high and low states. Propagation delay suitable for various communication speeds. Reliable industrial-grade bus transceiver for noise-prone environments.

Optimized for long twisted pair wiring in factory automation and control networks. Explore more semiconductor Line Interface ICs and bus transceivers in our Electronics & Electricals category at EnvMart for your industrial and communication system needs.
